The nas Commands
242
Celerra Network Server Command Reference Manual
The loaded option installs the image of the VDM onto the
physical Data Mover, but does not mount the non-root file
systems. The mounted option mounts the root_fs as read-only,
but the VDM image is not installed. The -setstate option is for use
with replication.
Note: Before a VDM image is loaded, the image must be unloaded from
the previous Data Mover, and the CIFS server must be joined using
server_cifs. The network interfaces used by the CIFS servers on the VDM
must be available on the destination Data Mover.
[-fs <fs_name> | pool=<pool>]
Specifies a file system or assigns a rule set known as a storage
pool for the VDM root file system.
For the -fs option, the file system must be unmounted and be
clean (see nas_fsck) and be either of type uxfs or rawfs. For a
loaded state VDM, only an uxfs file system type can be used, but
for mounted state VDM, both uxfs and rawfs can be used. The file
system to be provided as the VDM root file system is renamed to
root_fs_vdm_<vdm_name>. This is deleted when the VDM is
deleted.
The storage pool option assigns a rule set for the root file system
of the VDM that contains automatically created volumes and
defines the type of disk volumes used and how they are
aggregated. Storage pools are system defined (see storage pool
description above) or user defined (see nas_pool). See nas_pool for
a description of pool types.
[-option <options>]
Specifies the following comma-separated list of option(s):
fstype=rawfs
Specifies the file system type as rawfs when creating a mounted
VDM.
-vdm <vdm_name> -setstate <state>
Sets the state of the VDM to be loaded, mounted, tempunloaded, or
permunloaded.
The loaded option installs the image of the VDM onto the physical
Data Mover, but does not mount the non-root file systems. The
mounted option mounts the root_fs read-only, but the VDM image is
not installed.
