EMC Celerra Command Reference Manual page 466

The server Commands
EXAMPLE #5
$ server_sysconfig server_2 -virtual -name trk0_ec -create trk -option
"device=cge2,cge3"
server_2 : done
EXAMPLE #6
Value
Virtual Devices
devices
failsafe nic devices name of FSN virtual devices configured on the server.
trunking devices
EXAMPLE #7
$ server_sysconfig server_2 -virtual -info trk0_ec
server_2 :
*** Trunk trk0_ec: Link is Up ***
*** Trunk trk0_ec: Statistical Load Balancing is IP ***
Device Link Duplex Speed
------------------------------------------------------------------------
cge2 Up Full
cge3 Up Full
EXAMPLE #8
$ server_sysconfig server_2 -virtual -name fsn0 -create fsn -option "primary=cge2
device=cge2,cge3"
server_2 : done
EXAMPLE #9
466
Celerra Network Server Command Reference Manual
To create an Ethernet channel as a virtual device, type:
To display all virtual devices on server_2, type:
$ server_sysconfig server_2 -virtual
server_2 :
Virtual devices:
trk0_ec
fsn failsafe nic devices :
trk trunking devices : trk0_ec
Where:
Definition
all the configured virtual devices ( trunking or fail safe) on the server.
lists the virtual or physical device names that in the <virtual device>.
name of trunking virtual devices configured on the server.
To view information for the Ethernet channel, trk0_ec, type:
1000 Mbs
1000 Mbs
Where:
Value
Devices
Link
Duplex
Speed
To create a fail-safe network device as a virtual device, type:
To view the fail-safe network device, type:
$ server_sysconfig server_2 -virtual -info fsn0
server_2 :
*** FSN fsn0: Link is Up ***
active=cge2 primary=cge2 standby=cge3
devices=cge2 cge3
Definition
name of devices participating in this trunk.
status of the link on the specified device (can be up or down).
value of negotiated duplex. Values can be full or half.
value of negotiated speed.
