EMC Celerra Command Reference Manual page 495

Where:
Value Definition
unique VTLU identifier that is assigned automatically.
tlu_id
name of the file system associated with the VTLU.
filesystem
barcode_prefix modifiable prefix assigned to virtual tapes that is constant across a file system.
EXAMPLE #13
$ server_vtlu server_2 -tape -list 3
server_2 :
barcode filesystem
dstpre0001 ufs1
dstpre0002 ufs1
dstpre0003 ufs1
dstpre0004 ufs1
dstpre0005 ufs1
dstpre0006 ufs1
dstpre0000 ufs1
Where:
Value Definition
virtual tape barcode, consisting of the modifiable barcode prefix and a four-digit number that is assigned
barcode
automatically.
name of the file system.
filesystem
capacity (GB)virtual tape capacity in GB.
element type and element ID of the virtual tape; possible element types are slot, drive, import/export, robot, and
location
vault.
slot ID of the tape's previous location.
source_slot
EXAMPLE #14
EXAMPLE #15
EXAMPLE #16
$ server_vtlu server_2 -drive -list 3
server_2 :
drive_id
0
1
2
Where:
Value Definition
unique VTLU drive identifier that is assigned automatically.
drive_id
the device name of the VTLU drive.
device_name
To list VTLU information on VTLU 3, type:
capacity(GB)
1
1
1
1
1
1
1
To insert the specified tape in a virtual import/export slot on VTLU
3, type:
$ server_vtlu server_2 -tape -insert dstpre0001 -tlu 3
server_2 : done
To eject the specified tape from VTLU 3, type:
$ server_vtlu server_2 -tape -eject dstpre0001 -tlu 3
server_2 : done
To list the storage drive on VTLU 3, type:
device_name serial_number
c1t0l1 NXB2w4W000
c1t0l2 3u0bx4W000
c1t0l3 g0pgy4W000
location source_slot
vault
vault
vault
vault
vault
vault
impexp:0
status tape_barcode
empty
empty
empty
The server Commands
495
server_vtlu
