VLT AQUA Drive Programming Guide
Use par. 3-10 as another example:
Choose the parameter, press [OK], and use the up/down navigation keys keys to scroll through
the indexed values. To change the parameter value, select the indexed value and press [OK].
Change the value by using the up/down keys. Press [OK] to accept the new setting. Press [Cancel]
to abort. Press [Back] to leave the parameter.

1.1.15. How to operate numeric LCP (NLCP)

The following instructions are valid for the
NLCP (LCP 101).
The control panel is divided into four
functional groups:
1.
2.
3.
4.
Select one of the following modes:
Status Mode:
quency converter or the motor.
If an alarm occurs, the NLCP automatically
switches to status mode.
A number of alarms can be displayed.
Quick Setup or Main Menu Mode:
parameters and parameter settings.
Indicator lights (LEDs):
•
•
•
Menu key
[Menu]
modes:
•
•
is used for programming all parameters.
The parameters can be accessed immediately unless a password has been created via par. 0-60,
0-61, 0-65 or 0-66.
Numeric display.
Menu key and indicator lights (LEDs)
- changing parameters and switching
between display functions.
Navigation keys and indicator lights
(LEDs).
Operation keys and indicator lights
(LEDs).
NB!
Parameter copy is not possible
with Numeric Local Control Pan-
el (LCP101).
Displays the status of the fre-
Green LED/On: Indicates if control
section is on.
Yellow LED/Wrn.: Indicates a warn-
ing.
Flashing red LED/Alarm: Indicates
an alarm.
Select one of the following
Status
Quick Setup
®
MG.20.O2.02 - VLT is a registered Danfoss trademark
Illustration 1.14: Numerical LCP (NLCP)
Illustration 1.15: Status display example
Display
Illustration 1.16: Alarm display example
• Main Menu
Main Menu
1. How to Programme
