1. How to Programme

1.1. Local Control Panel

1.1.1. How to operate graphical LCP (GLCP)

The following instructions are valid for the GLCP (LCP 102).
The GLCP is divided into four functional groups:
1.
2.
3.
4.
Graphical display:
The LCD-display is back-lit with a total of 6 alpha-numeric lines. All data is displayed on the LCP
which can show up to five operating variables while in [Status] mode.
Display lines:
a.
b.
c.
Graphical display with Status lines.
Menu keys and indicator lights (LED's) - selecting mode, changing parameters and
switching between display functions.
Navigation keys and indicator lights (LEDs).
Operation keys and indicator lights (LEDs).
Status line: Status messages displaying icons and graphics.1
Line 1-2: Operator data lines displaying data and variables defined or chosen by the
user. By pressing the [Status] key, up to one extra line can be added.1
Status line: Status messages displaying text.1
®
