VLT
AQUA Drive
Operating Instructions
Contents
®
MG.20.M4.02 - VLT
is a registered Danfoss trademark
Contents
3
3
3
3
5
6
6
6
7
7
8
11
12
15
15
16
23
23
26
31
32
37
45
45
46
49
49
49
54
57
61
61
62
62
65
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VLT AQUA Drive and is the answer not in the manual?

Questions and answers

Related Manuals for Danfoss VLT AQUA Drive

Summary of Contents for Danfoss VLT AQUA Drive

  • Page 1: Table Of Contents

    How to operate graphical LCP (GLCP) How to operate numeric LCP (NLCP) Tips and tricks 8. How to programme the frequency converter How to programme Q1 My Personal Menu Q2 Quick Setup Q5 Changes Made ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 2 Cascade Controller 25-** Analog I/O Option MCB 109 26-** Cascade CTL Option 27-** Water Application Functions 29-** Bypass Option 31-** 9. Troubleshooting Warning/Alarm list 10. Specifications General Specifications Special Conditions Index ® MG.20.M4.02 - VLT is a registered Danfoss trademark...

  • Page 3: How To Read These Operating Instructions

    These Operating Instructions will introduce all aspects of your VLT AQUA Drive. Available literature for VLT AQUA Drive: Operating Instructions MG.20.MX.YY provide the neccessary information for getting the drive up and running.
  • Page 4 ® AQUA Drive 1. How to Read these Operating Instructions Operating Instructions Indicates a general warning. Indicates a high-voltage warning. Indicates default setting ® MG.20.M4.02 - VLT is a registered Danfoss trademark...

  • Page 5: Safety

    Installation at High Altitudes By altitudes above 2 km, please contact Danfoss regarding PELV. Warning against Unintended Start 1. The motor can be brought to a stop by means of digital commands, bus commands, references or a local stop, while the frequency converter is connected to mains.

  • Page 6: General Warning

    Leakage Current The earth leakage current from the VLT AQUA Drive FC 200 exceeds 3.5 mA. According to IEC 61800-5-1 a reinforced Protective Earth connection must be ensured by means of: a min. 10mm² Cu or 16mm² Al PE-wire or an addtional PE wire - with the same cable cross section as the Mains wiring - must be terminated separately.

  • Page 7: Avoid Unintended Start

    In order to install and use the Safe Stop function in accordance with the requirements of Safety Category 3 in EN 954-1, the related information and instructions of the VLT AQUA Drive Design Guide MG.20.NX.YY must be followed! The information and instructions of the Operating Instructions are not sufficient for a correct and safe use of the Safe Stop functionality! ®...

  • Page 8: It Mains

    2.1.9. Software Version and Approvals: VLT AQUA Drive VLT AQUA Drive Operating Instructions Software version: 1.05 This Operating Instructions can be used for all VLT AQUA Drive frequency converters with software version 1.05. The software version number can be seen from parameter 15-43. ® MG.20.M4.02 - VLT...
  • Page 9 Equipment containing electrical components must not be disposed of together with domestic waste. It must be separately collected with electrical and electronic waste according to local and currently valid leg- islation. ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 10 ® AQUA Drive 3. Introduction Operating Instructions ® MG.20.M4.02 - VLT is a registered Danfoss trademark...

  • Page 11: Introduction

    Below is an example of an identification label. This label is situated on the frequency converter and shows the type and options fitted to the unit. See table 2.1 for details of how to read theType code string (T/C). Illustration 3.1: This example shows an identification label for VLT AQUA Drive. Please have T/C (type code) number and serial number ready before contacting Danfoss.

  • Page 12: Type Code String

    36-37 XX: Standard software DX: No option D options 38-39 D0: DC back-up Table 3.1: Type code description. The various options are described further in the VLT AQUA Drive Design Guide. ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 13 Pa = N/m² psi, psf, ft of water Rated Inverter Output Current Revolutions Per Minute Size Related Temperature ˚C ˚F Time s,hr Torque limit Voltage Table 3.2: Abbreviation and Standards table . ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 14 ® AQUA Drive 4. Mechanical installation Operating Instructions ® MG.20.M4.02 - VLT is a registered Danfoss trademark...

  • Page 15: Mechanical Installation

    The packaging for these enclosures contains, as shown: Accessories bag(s), documentation and the unit. Depending on options fitted there may be one or two bags and one or more booklets. ® MG.20.M4.02 - VLT is a registered Danfoss trademark...

  • Page 16: How To Install

    The frequency converter can be mounted side by side for all IP rating units and requires 100 mm free space above and below for cooling. With regard to ambient temperature ratings, please see Special Conditions. ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 17 ® AQUA Drive Operating Instructions 4. Mechanical installation Illustration 4.1: Side by side mounting of all frame sizes. Illustration 4.2: This is the correct way to mount the unit. ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 18 Illustration 4.4: If the unit must be mounted a small distance from the wall please order the back plate with the unit (see Ordering type code position 14-15). A2 and A3 units have back-plate as standard. ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 19 Step 2A: This way it is easy to hang the unit on the screws. Step 4: Tighten screws completely. Illustration 4.7: Wrong mounting of screws. Step 2B: Do not tighten screws completely. ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 20 5.3 kg 6.6 kg 7.0 kg Table 4.3: A2 and A3 mechanical dimensions Option A/B are serial communication and I/O options, which when fitted increase the depth on some enclosure sizes. ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 21 Step 2A: This way it is easy to hang the unit on the screws. Illustration 4.14: Tightening of screws Step 4: Tighten screws completely. Illustration 4.12: Wrong mounting of screws Step 2B: Do not tighten screws completely. ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 22 Table 4.4: A5, B1, B2, B3, B4, C3 and C4 mechanical dimensions. 1) The dimensions state the maximum height, width and depth needed for mounting the frequency converter, when the top cover is mounted. ® MG.20.M4.02 - VLT is a registered Danfoss trademark...

  • Page 23: Electrical Installation

    Non UL compliance If UL/cUL is not to be complied with, Danfoss recommends using the fuses mentioned in table 4.2, which will ensure compliance with EN50178: In case of malfunction, not following the recommendation may result in unnecessary damage to the frequency converter.
  • Page 24 JKS-150 JJN-125 2028220-125 KLN-R125 A2K-125R KTN-R125 JKS-150 JJN-125 2028220-125 KLN-R125 A2K-125R FWX-150 2028220-150 L25S-150 A25X-150 FWX-200 2028220-200 L25S-200 A25X-200 FWX-250 2028220-250 L25S-250 A25X-250 Table 5.3: UL fuses 200 - 240 V ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 25 L50S fuses from LITTEL FUSE may substitute L50S fuses for 240 V frequency converters. A6KR fuses from FERRAZ SHAWMUT may substitute A2KR for 240 V frequency converters. A50X fuses from FERRAZ SHAWMUT may substitute A25X for 240 V frequency converters. ® MG.20.M4.02 - VLT is a registered Danfoss trademark...

  • Page 26: Mains Wiring Overview

    11-15 kW 18.5-22 kW 30-45 kW 380-480 V 0.37-4.0 kW 5.5-7.5 kW 0.37-7.5 kW 11-18.5 kW 22-30 kW 37-55 kW 75-90 kW Goto: 5.1.5 5.1.6 5.1.7 5.1.8 Table 5.5: Mains wiring table. ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 27 Illustration 5.3: When mounting cables, first mount and tighten earth cable. The earth connection cable cross section must be at least 10 mm or 2 rated mains wires terminated separately according to EN 50178/ IEC 61800-5-1 ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 28 ® AQUA Drive 5. Electrical installation Operating Instructions Illustration 5.4: Then mount mains plug and tighten wires. Illustration 5.5: Finally tighten support bracket on mains wires. ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 29 Illustration 5.6: How to connect to mains and earthing without mains disconnect switch. Note that a cable clamp is used. Illustration 5.7: How to connect to mains and earthing with mains disconnect switch. ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 30 Illustration 5.8: How to connect to mains and earthing for B1 and B2. Illustration 5.10: How to connect to mains and earthing for B3 without RFI. For correct cable dimensions please see the section General Specifications at the back of this manual. ® MG.20.M4.02 - VLT is a registered Danfoss trademark...

  • Page 31: How To Connect Motor - Foreword

    Furthermore, the terminal screw must be retightened after two days due to the softness of the aluminium. It is crucial to ensure the connection makes a gas tight joint, otherwise the aluminium surface will oxidize again. ® MG.20.M4.02 - VLT is a registered Danfoss trademark...

  • Page 32: Motor Wiring Overview

    IP 55/IP 66) Motor size: 0.25-3.0 0.25-3.7 5.5-7.5 11-15 18.5-22 30-45 200-240 V 0.37-4.0 5.5-7.5 0.37-7.5 11-18.5 22-30 37-55 75-90 380-480 V Goto: 5.1.11 5.1.12 5.1.13 5.1.14 Table 5.7: Motor wiring table. ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 33 Illustration 5.13: First terminate the motor earth, then place motor U, V and W wires in plug and tighten. Illustration 5.14: Mount cable clamp to ensure 360 degree connection between chassis and screen, note the outer insulation of the motor cable is removed under the clamp. ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 34 Illustration 5.16: First terminate the motor earth, then Place motor U, V and W wires in terminal and tighten. Please ensure that the outer insulation of the motor cable is removed under the EMC clamp. ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 35 The following section describes how to terminate control wires and how to access them. For an explanation of the function, programming and wiring of the control terminals, please see chapter, How to programme the frequency converter. ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 36 Remove front-cover to access control terminals. When replacing the front-cover, please ensure proper fastening by applying a torque of 2 Nm. Illustration 5.19: Access to control terminals for A5, B1,B2, C1 and C2 enclosures ® MG.20.M4.02 - VLT is a registered Danfoss trademark...

  • Page 37: How To Test Motor And Direction Of Rotation

    (Note: For units with Safe Stop function, the existing jumper piece of wire. between terminal 12 and 37 should not be removed for the unit to be able to run!) ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 38 7 regarding these. Illustration 5.27: Step 7: To move the cursor, use the left and right arrow buttons. ◄ ◄ This enables changing the speed in larger increments. ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 39 Step 8: Press the [Off] button to stop the motor again. Illustration 5.29: Step 9: Change two motor wires if the desired rotation of direction is not achieved. Remove mains power from the frequency converter before changing motor wires. ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 40 The common of digital / analog inputs and outputs should be connected to separate common terminals 20, 39, and 55. This will avoid ground current interference among groups. For example, it avoids switching on digital inputs disturbing analog inputs. Control cables must be screened/armoured. ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 41 Please note that the switches may be covered by an option, if fitted. Default setting: S201 (AI 53) = OFF (voltage input) S202 (AI 54) = OFF (voltage input) S801 (Bus termination) = OFF Illustration 5.32: Switches location. ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 42 To access list first press [QUICK MENU] key then select “Q2 Quick Setup”. or Motor Power [HP] par. 1-21 Motor Voltage par. 1-22 Motor Frequency par. 1-23 Motor Current par. 1-24 Motor Nominal Speed par. 1-25 Table 5.8: Motor related parameters ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 43 "Report Value” in the [Alarm Log] shows the last measuring sequence carried out by the AMA, before the frequency converter entered alarm mode. This number along with the description of the alarm will assist troubleshooting. If contacting Danfoss Service, make sure to mention number and alarm description.
  • Page 44 ® AQUA Drive 6. Application Examples Operating Instructions ® MG.20.M4.02 - VLT is a registered Danfoss trademark...

  • Page 45: Application Examples

    Terminal 12 /13: +24V DC Terminal 18: Start par. 5-18 [8] Start (Default) Terminal 27: Coast par. 5-12 [2] coast inverse (Default) Terminal 54: Analog input L1-L3: Mains terminals U,V and W: Motor terminals ® MG.20.M4.02 - VLT is a registered Danfoss trademark...

  • Page 46: Submersible Pump Application

    The system consists of a submersible pump controlled by a Danfoss VLT AQUA Drive and a pressure transmitter. The transmitter gives a 4-20 mA feedback signal to the VLT AQUA Drive, which keeps a constant pressure by controlling the speed of the pump. To design a drive for a submersible pump application, there are a few important issues to take into consideration.
  • Page 47 Use the “Closed Loop” wizard under “Quick Menu_Funtion_Setup”, to easily set up the feedback settings in the PID controller. Pipe Fill Mode Pipe Fill Enable Par. 29-00 Pipe Fill Rate Par. 29-04 (Feedback units/sec.) Filled Set Point Par. 29-05 (Feedback units) ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 48 ® AQUA Drive 7. How to operate the frequency converter Operating Instructions ® MG.20.M4.02 - VLT is a registered Danfoss trademark...

  • Page 49: How To Operate The Frequency Converter

    Operator data lines displaying data and variables defined or chosen by the user. By pressing the [Status] key, up to one extra line can be added.1 Status line: Status messages displaying text.1 ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 50 (1.1, 1.2, 1.3, 2, and 3). See the operating variables shown in the display in this illustration. 1.1, 1.2 and 1.3 are shown in small size. 2 and 3 are shown in medium size. ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 51 Menu keys The menu keys are divided into functions. The keys below the display and indicator lamps are used for parameter set-up, including choice of display indication during normal operation. 130BP045.10 ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 52 [Info] provides detailed information when needed. [Cancel] Exit Info mode by pressing either [Info], [Back], or [Cancel]. last change or command will be cancelled as long as the display has not been changed. ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 53 An active HAND-OFF-AUTO signal via the digital inputs has higher priority than the control keys [Hand on] – [Auto on]. [Reset] Enabled Disabled Reset Keys on LCP is used for resetting the frequency converter after an alarm (trip). The key can be [1] or [0] via par. 0-43 ® MG.20.M4.02 - VLT is a registered Danfoss trademark...

  • Page 54: How To Operate Numeric Lcp (Nlcp)

    Select Main Menu by pressing the [Menu] key a number of times until the Main Menu LED is lit. Select the parameter group [xx-__] and press [OK] Select the parameter [__-xx] and press [OK] If the parameter is an array parameter select the array number and press [OK] ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 55 An active HAND-OFF-AUTO signal via the digital inputs has higher priority than the control keys [Hand on] [Auto on]. [Reset] Enabled Disabled Reset Keys on LCP is used for resetting the drive after an alarm (trip). The key can be [1] or [0] via par. 0-43 ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 56 Certain parameters can be changed step by step or infinitely variably. This applies to (par. 1-20), (par. 1-22) and Frequency (par. 1-23). The parameters are changed both as a group of numeric data values and as numeric data values infinitely variably. ® MG.20.M4.02 - VLT is a registered Danfoss trademark...

  • Page 57: Tips And Tricks

    Select “All from LCP” Press the [OK] key The parameter settings stored in the GLCP are now transferred to the frequency converter indicated by the progress bar. When 100% is reached, press [OK]. ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 58 P signal (TX+, RX+), while terminal 69 is connected to the N signal (TX-,RX-). If more than one frequency converter is connected to a master, use par- allel connections. Illustration 7.9: Connection example. ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 59 The USB connection is galvanically isolated from the supply voltage (PELV) and other high-voltage terminals. The USB connection is connected to protection earth on the frequency converter. Use only isolated laptop as PC connection to the USB connector on the frequency converter. Illustration 7.10: USB Connection ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 60 7.1.14. PC Software tools PC Software - MCT 10 All Frequency converters are equipped with a serial communication port. Danfoss provides a PC tool for communication between PC and frequency converter, VLT Motion Control Tool MCT 10 Set-up Software. MCT 10 Set-up Software MCT 10 has been designed as an easy to use interactive tool for setting parameters in our frequency converters.

  • Page 61: How To Programme The Frequency Converter

    Press [Function Setups] for setting up the required functionality of the frequency converter - if not already covered by the settings in [Quick Setup]. General Settings Open Loop Settings Closed Loop Settings. Choose between ® MG.20.M4.02 - VLT is a registered Danfoss trademark...

  • Page 62: Q1 My Personal Menu

    1-25 Motor Nominal Speed 3-41 Ramp 1 Ramp Up Time 3-42 Ramp 1 Ramp Down Time 4-11 Motor Speed Low Limit 4-13 Motor Speed High Limit 1-29 Automatic Motor Adaptation (AMA) ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 63 Illustration 8.8: Step 7: Use the up/down navigation keys to select be- tween the different choices. Press [OK]. Illustration 8.5: Step 4: Function Setups choices appear. Choose 03-1 General Settings . Press [OK]. ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 64 20-94 PID Integral Time 6-21 Terminal 54 High Voltage 6-24 Terminal 54 Low Ref/Feedb Value 6-25 Terminal 54 High Ref/Feedb Value 6-00 Live Zero Timeout Time 6-01 Live Zero Timeout Function ® MG.20.M4.02 - VLT is a registered Danfoss trademark...

  • Page 65: Q5 Changes Made

    Please notice that the parameters listed in the below table for Q6 only serve as examples as they will vary depending on the programming of the particular frequency converter. Q6 Loggings Reference Analog Input 53 Motor Current Frequency Feedback Energy Log Trending Cont Bin Trending Timed Bin Trending Comparison ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 66 Special Functions Drive Information Data Readouts Data Readouts 2 Drive Closed Loop Ext. Closed Loop Application Functions Time-based Functions Fire Mode Cascade Controller Analog I/O Option MCB 109 Table 8.3: Parameter groups. ® MG.20.M4.02 - VLT is a registered Danfoss trademark...

  • Page 67: Common Used Parameters - Explanations

    For a detailed explanation of all parameters, please refer to the VLT AQUA Drive Programming Guide MG.20.OX.YY which is available on www.danfoss.com or by ordering at the local Danfoss office. 8.2.2. 0-** Operation / Display Parameters related to the fundamental functions of the frequency converter, function of the LCP buttons and configuration of the LCP display.
  • Page 68 Actual value at input 53 either as a reference or protection value. [1663] Terminal Switch Setting of input terminal 54. Current = 0; Voltage = 1. Setting [1664] Analog Input 54 Actual value at input 54 either as reference or protection value. ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 69 The calculated No Flow Power for the actual operating speed [2580] Cascade Status Status for the operation of the Cascade Controller [2581] Pump Status Status for the operation of each individual pump controlled by the Cascade Controller ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 70 In this parameter it is possible to write an individual text string for display in the LCP or to be read via serial communication. If to be displayed permanently select Display Text 3 in par. 0-20, par. 0-21, par. 0-22, par. 0-23 ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 71 Motor speed is determined by applying a speed reference or by setting desired speed when in Hand Mode. Open Loop is also used if the frequency converter is part of a closed loop control system based on an external PID controller providing a speed reference signal as output. ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 72 1-29 Automatic Motor Adaptation (AMA) Option: Function: The AMA function optimizes dynamic motor performance by automatically optimizing the advanced motor pa- rameters (par. 1-30 to par. 1-35) while the motor is stationary. No function ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 73 . Afterwards, the value is added to Ref . When using preset references, select Preset ref. bit 0 / 1 / 2 [16], [17] or [18] for the corresponding digital inputs in parameter group 5.1* Digital Inputs. ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 74 Set the speed in Hz below motor speed low limit where the Check Valve Ramp Time will no longer be used. Motor Speed Low Limit [0 – Motor Speed Low Limit] ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 75 Any changes in par. 4-13 will reset the value in par. 4-53 to the same value as set in par. 4-13. 8.2.6. 5-** Digital In/Out Parameter group for configuring the digital input and output. ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 76 Stop Inverted function. Generates a stop function when the selected terminal goes from logical level ‘1’ to ‘0’. The stop is performed according to the selected ramp time (par. 3-42, par. 3-52, par. 3-62, par. 3-72). ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 77 [23] Set-up select bit 0 Selects one of the four set-ups. Set par. 0-10 Active Set-up to Multi Set-up. [24] Set-up select bit 1 Same as Set-up select bit 0 [23]. ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 78 Pump2 to the pump controlled by the relay RELAY1. Variable speed pump (lead) cannot be interlocked in the basic Cascade Controller. See below table: ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 79 Run on Ref./No Warn- Alarm [10] Alarm or Warning [11] At Torque Limit [12] Out of Current Range [13] Below Current, low [14] Above Current, high [15] Out of Speed Range ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 80 [160] No Alarm [161] Running Reverse [165] Local Ref. Active [166] Remote Ref. Active [167] Start Cmd. Active [168] Drive in Hand Mode [169] Drive in Auto Mode [180] Clock Fault ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 81 If you select set-up 1-4, par. 0-10, Active Set-up , must be set to Multi Set-up , [9]. This parameter cannot be adjusted while the motor is running. Freeze output Stop Jogging Max. speed Stop and trip ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 82 6-24 Terminal 54 Low Ref./Feedb. Value Range: Function: Enter the analog input scaling value that corresponds to the low voltage/low current value set in par. 6-20 and 0.000 Unit [-1000000.000 to par. par. 6-22. 6-25] ® MG.20.M4.02 - VLT is a registered Danfoss trademark...

  • Page 83: Fc Closed Loop 20

    Values for setting the Minimum Reference is found in par. 3-02 and par. 20-13 - values for Maximum Reference is found in Open Loop Closed Loop par. 3-03 and par. 20-14 ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 84 Output signal 0 or 4 mA is needed at 0 Hz (0% of range) - set par. 6-51 to 0% Output signal 20 mA is needed at 50 Hz (100% of range) - set par. 6-52 to 50% ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 85 This parameter group is used for configuring the closed loop PID Controller, that controls the output frequency of the frequency converter. 20-12 Reference/Feedback Unit Option: Function: None [10] 1/min [11] [12] Pulse/s [20] ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 86 Hg [180] This parameter determines the unit that is used for the setpoint reference and feedback that the PID Controller will use for controlling the output frequency of the frequency converter. ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 87 , an auto set up sequence is activated, automatically setting speed to approx. 50 and 85% of rated motor speed (par. 4-13/14, Motor Speed High Limit ). At those two speeds, the power consumption is automatically measured and stored. Before enabling Auto Set Up: ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 88 Set the time Low Power/Low Speed must stay detected to activate signal for actions. If detection disappears 10 sec. [0-600 sec.] before run out of the timer, the timer will be reset. ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 89 , has been set for RPM (parameter not visible if Hz selected). 0 RPM [0.0 - par. 4-13 (Motor High Set used speed for the 85% level. Speed Limit)] The function is used for storing values needed to tune No Flow Detection. ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 90 If used in application where the integrated PI controller is set for inverse control in par. 20-71, PID, Normal/Inverse Control , the value set in par. 22-44 will automatically be added. ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 91 Range: Function: Example 1: Adjustment of this parameter allows the shape of the control curve to be adjusted. 0 = Linear 100% = Ideal shape (theoretical). 100% [ 0 – 100%] ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 92 Knowing these two points on the pump curve, along with H as described above, allows the frequency converter to calculate the reference point B and thus to plot the control curve which will also include the System design Working Point A. ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 93 Range: Function: Enter the value corresponding to the Pressure at Rated Speed, in Reference/Feedback Units. This value can be 0 Reference/ Feedback Units [0 - defined using the pump datasheet. 999999.999] ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 94 SL Controller Action Select the action during ON Time. See par. 13.52 for descriptions of the options. Array [10] DISABLED No action Select setup 1 Select setup 2 Select setup 3 ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 95 Start timer 4 [72] Start timer 5 [73] Start timer 6 [74] Start timer 7 23-02 OFF Time Array [10] Sets the OFF time for the Timed Action. 00:00:00 [00:00:00 –23:59:59] ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 96 Set dig. out. F low [38] Set dig. out. A high [39] Set dig. out. B high [40] Set dig. out. C high [41] Set dig. out. D high [42] Set dig. out. E high ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 97 Select which day(s) the Timed Action applies to. Specify working/non-working days in par. 0-81, 0-82 and 0-83. Array [10] All days Working days Non-working days Monday Tuesday Wednesday Thursday Friday Saturday Sunday ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 98 Specifies the Filled Setpoint at which the Pipe Fill Function will be disabled and PID controller will take control. [0 – 999999,999] This can be used both for horizontal and vertical pipe systems. ® MG.20.M4.02 - VLT is a registered Danfoss trademark...

  • Page 99: Parameter Options

    Unsigned 8 Uint8 Unsigned 16 Uint16 Unsigned 32 Uint32 Visible String VisStr Normalized value 2 bytes Bit sequence of 16 boolean variables Time difference w/o date TimD SR = Size related ® MG.20.M4.02 - VLT is a registered Danfoss trademark...

  • Page 100: Operation/Display 0

    ® AQUA Drive 8. How to programme the frequency converter Operating Instructions ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 101 ® AQUA Drive Operating Instructions 8. How to programme the frequency converter ® MG.20.M4.02 - VLT is a registered Danfoss trademark...

  • Page 102: Load/Motor 1

    ® AQUA Drive 8. How to programme the frequency converter Operating Instructions ® MG.20.M4.02 - VLT is a registered Danfoss trademark...

  • Page 103: Brakes 2

    ® AQUA Drive Operating Instructions 8. How to programme the frequency converter ® MG.20.M4.02 - VLT is a registered Danfoss trademark...

  • Page 104: Reference / Ramps 3

    ® AQUA Drive 8. How to programme the frequency converter Operating Instructions ® MG.20.M4.02 - VLT is a registered Danfoss trademark...

  • Page 105: Limits / Warnings 4

    ® AQUA Drive Operating Instructions 8. How to programme the frequency converter ® MG.20.M4.02 - VLT is a registered Danfoss trademark...

  • Page 106: Digital In/Out 5

    ® AQUA Drive 8. How to programme the frequency converter Operating Instructions ® MG.20.M4.02 - VLT is a registered Danfoss trademark...

  • Page 107: Analog In/Out 6

    ® AQUA Drive Operating Instructions 8. How to programme the frequency converter ® MG.20.M4.02 - VLT is a registered Danfoss trademark...

  • Page 108: Comm. And Options 8

    ® AQUA Drive 8. How to programme the frequency converter Operating Instructions ® MG.20.M4.02 - VLT is a registered Danfoss trademark...

  • Page 109: Profibus 9

    ® AQUA Drive Operating Instructions 8. How to programme the frequency converter ® MG.20.M4.02 - VLT is a registered Danfoss trademark...

  • Page 110: Can Fieldbus 10

    ® AQUA Drive 8. How to programme the frequency converter Operating Instructions ® MG.20.M4.02 - VLT is a registered Danfoss trademark...

  • Page 111: Smart Logic 13

    ® AQUA Drive Operating Instructions 8. How to programme the frequency converter ® MG.20.M4.02 - VLT is a registered Danfoss trademark...

  • Page 112: Special Functions 14

    ® AQUA Drive 8. How to programme the frequency converter Operating Instructions ® MG.20.M4.02 - VLT is a registered Danfoss trademark...

  • Page 113: Fc Information 15

    ® AQUA Drive Operating Instructions 8. How to programme the frequency converter ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 114 ® AQUA Drive 8. How to programme the frequency converter Operating Instructions ® MG.20.M4.02 - VLT is a registered Danfoss trademark...

  • Page 115: Data Readouts 16

    ® AQUA Drive Operating Instructions 8. How to programme the frequency converter ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 116 ® AQUA Drive 8. How to programme the frequency converter Operating Instructions ® MG.20.M4.02 - VLT is a registered Danfoss trademark...

  • Page 117: Data Readouts 2 18

    ® AQUA Drive Operating Instructions 8. How to programme the frequency converter ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 118 ® AQUA Drive 8. How to programme the frequency converter Operating Instructions ® MG.20.M4.02 - VLT is a registered Danfoss trademark...

  • Page 119: Ext. Closed Loop 21

    ® AQUA Drive Operating Instructions 8. How to programme the frequency converter ® MG.20.M4.02 - VLT is a registered Danfoss trademark...

  • Page 120: Application Functions 22

    ® AQUA Drive 8. How to programme the frequency converter Operating Instructions ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 121 ® AQUA Drive Operating Instructions 8. How to programme the frequency converter ® MG.20.M4.02 - VLT is a registered Danfoss trademark...

  • Page 122: Timed Actions 23

    ® AQUA Drive 8. How to programme the frequency converter Operating Instructions ® MG.20.M4.02 - VLT is a registered Danfoss trademark...

  • Page 123: Cascade Controller 25

    ® AQUA Drive Operating Instructions 8. How to programme the frequency converter ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 124 ® AQUA Drive 8. How to programme the frequency converter Operating Instructions ® MG.20.M4.02 - VLT is a registered Danfoss trademark...

  • Page 125: Analog I/O Option Mcb 109 26

    ® AQUA Drive Operating Instructions 8. How to programme the frequency converter ® MG.20.M4.02 - VLT is a registered Danfoss trademark...

  • Page 126: Cascade Ctl Option 27

    ® AQUA Drive 8. How to programme the frequency converter Operating Instructions ® MG.20.M4.02 - VLT is a registered Danfoss trademark...

  • Page 127: Water Application Functions 29

    ® AQUA Drive Operating Instructions 8. How to programme the frequency converter ® MG.20.M4.02 - VLT is a registered Danfoss trademark...

  • Page 128: Bypass Option 31

    ® AQUA Drive 8. How to programme the frequency converter Operating Instructions ® MG.20.M4.02 - VLT is a registered Danfoss trademark...

  • Page 129: Troubleshooting

    Via a digital input with the “Reset” function. Via serial communication/optional fieldbus. By resetting automatically using the [Auto Reset] function, which is a default setting for VLT AQUA Drive. see par. 14-20 Reset Mode in AQUA Drive Programming Guide After a manual reset using the [RESET] button on the LCP, the [AUTO ON] or [HAND ON] button must be pressed to restart the motor.
  • Page 130 Option Configuration has Changed Safe Stop Activated Drive Initialised to Default Value Table 9.1: Alarm/Warning code list (X) Dependent on parameter LED indication Warning yellow Alarm flashing red Trip locked yellow and red ® MG.20.M4.02 - VLT is a registered Danfoss trademark...

  • Page 131: Warning/Alarm List

    If no 24 V backup supply is connected, the frequency converter trips after verter trips after a time. a given time depending on the unit. Connect a brake resistor. Extend the ramp time ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 132 008000 Out of frequency range in extended status word is active but Brake quency converter and replace the brake resistor (see par. 2-15 there is no warning in the display. Check ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 133 [RESET]). For correct and safe use of the Safe Stop function follow the related information and instructions in the Design Guide ALARM 70, Illegal Frequency Configuration: Actual combination of control board and power board is illegal. ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 134 ® AQUA Drive 10. Specifications Operating Instructions ® MG.20.M4.02 - VLT is a registered Danfoss trademark...

  • Page 135: Specifications

    ® AQUA Drive Operating Instructions 10. Specifications 10. Specifications 10.1. General Specifications ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 136 ® AQUA Drive 10. Specifications Operating Instructions ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 137 ® AQUA Drive Operating Instructions 10. Specifications ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 138 ® AQUA Drive 10. Specifications Operating Instructions ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 139 ® AQUA Drive Operating Instructions 10. Specifications ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 140 ® AQUA Drive 10. Specifications Operating Instructions ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 141 ® AQUA Drive Operating Instructions 10. Specifications ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 142 ® AQUA Drive 10. Specifications Operating Instructions ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 143 ® AQUA Drive Operating Instructions 10. Specifications ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 144 Starting torque maximum 135% up to 0.5 sec. Overload torque (Constant torque) maximum 110% for 1 min. *Percentage relates to VLT AQUA Drive's nominal torque. Cable lengths and cross sections: Max. motor cable length, screened/armoured VLT AQUA Drive: 150 m Max.
  • Page 145 10 bit (+ sign) Accuracy of analog inputs Max. error 0.5% of full scale Bandwidth : 200 Hz The analog inputs are galvanically isolated from the supply voltage (PELV) and other high-voltage terminals. ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 146 Control card, 10 V DC output: Terminal number Output voltage 10.5 V ±0.5 V Max. load 25 mA The 10 V DC supply is galvanically isolated from the supply voltage (PELV) and other high-voltage terminals. ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 147 The USB connection is galvanically isolated from the supply voltage (PELV) and other high-voltage terminals. The USB connection is not galvanically isolated from protection earth. Use only isolated laptop/PC as connection to the USB connector on VLT AQUA Drive or an isolated USB cable/converter. ®...
  • Page 148 Based on the graph outlined above, it is possible to calculate the system efficiency at different speeds. The acoustic noise from the frequency converter comes from three sources: DC intermediate circuit coils. Integral fan. RFI filter choke. ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 149 In motors without phase insulation paper or other insulation reinforcement suitable for operation with voltage supply (such as a frequency converter), fit a du/dt filter or a sine-wave filter on the output of the frequency converter. ® MG.20.M4.02 - VLT is a registered Danfoss trademark...

  • Page 150: Special Conditions

    Illustration 10.4: Derating of I for different T for enclosure A, AMB, MAX AMB, MAX using 60 AVM and maximum 10 m motor cable using SFAVM and maximum 10 m motor cable ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 151 AMB, MAX AMB, MAX at 480 V, using 60 AVM in Normal torque mode (110% over torque) D at 480 V, using SFAVM in Normal torque mode (110% over torque) ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 152 E AMB, MAX AMB, MAX at 480 V, using 60 AVM in Normal torque mode (110% over torque) at 480 V, using SFAVM in Normal torque mode (110% over torque) ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 153 (or a motor designed for this type of operation may be used). An alternative is to reduce the load level of the motor by choosing a larger motor. However, the design of the frequency converter puts a limit to the motor size. ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 154 As a response to a critical level, the frequency converter can adjust the switching frequency and / or change the switching pattern in order to ensure the performance of the frequency converter. The capability to automatically reduce the output current extends the acceptable operating conditions even further. ® MG.20.M4.02 - VLT is a registered Danfoss trademark...

  • Page 155: Index

    Derating For Ambient Temperature Derating For Installing Long Motor Cables Or Cables With Larger Cross-section Derating For Low Air Pressure Derating For Running At Low Speed Digital In/out Digital Inputs: Digital Output ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 156 How To Operate Graphical Lcp (glcp) How To Read The Parameter Tabels Indexed Parameters Indicator Lights (leds): Initial Ramp Time Initialisation Installation At High Altitudes Intermediate Circuit 131, 148, 149 Kty Sensor Language 54, 57 ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 157 Parameter Selection Parameter Set-up Pc Software Tools Peak Voltage On Motor Pid Integral Time, 20-94 Pid Normal/inverse Control, 20-81 Pid Proportional Gain, 20-93 Pid Start Speed [rpm], 20-82 Pipe Fill Rate, 29-04 ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 158 Terminal 32 Digital Input, 5-14 Terminal 33 Digital Input, 5-15 Terminal 42 Output Max Scale 6-52 Terminal 42 Output Min Scale, 6-51 Terminal 42 Output, 6-50 Terminal 53 High Voltage, 6-11 ® MG.20.M4.02 - VLT is a registered Danfoss trademark...
  • Page 159 Type Code String Type Code String (t/c). Usb Connection. Voltage Level Wake-up Ref./fb Difference Wake-up Speed [rpm], 22-42 Warning Against Unintended Start Water Application Functions Wiring Example And Testing Work Point Calculation, 22-82 ® MG.20.M4.02 - VLT is a registered Danfoss trademark...

Table of Contents
