VLT AQUA Drive
Operating Instructions
[Reset
is used for resetting the frequency converter after an alarm (trip). The key can be
Disabled
The parameter shortcut
can be carried out by holding down the [Main Menu] key for 3 seconds. The parameter shortcut
allows direct access to any parameter.

6.1.3. How to operate numeric LCP (NLCP)

The following instructions are valid for the
NLCP (LCP 101).
The control panel is divided into four
functional groups:
1.
2.
3.
4.
Select one of the following modes:
Status Mode:
quency converter or the motor.
If an alarm occurs, the NLCP automatically
switches to status mode.
A number of alarms can be displayed.
Quick Setup or Main Menu Mode:
parameters and parameter settings.
Indicator lights (LEDs):
•
•
•
Menu key
[Menu]
modes:
•
•
is used for programming all parameters.
The parameters can be accessed immediately unless a password has been created via par. 0-60,
0-61, 0-65 or 0-66.
Reset Keys on LCP
[0] via par. 0-43
Numeric display.
Menu key and indicator lights (LEDs)
- changing parameters and switching
between display functions.
Navigation keys and indicator lights
(LEDs).
Operation keys and indicator lights
(LEDs).
NB!
Parameter copy is not possible
with Numeric Local Control Pan-
el (LCP101).
Displays the status of the fre-
Green LED/On: Indicates if control
section is on.
Yellow LED/Wrn.: Indicates a warn-
ing.
Flashing red LED/Alarm: Indicates
an alarm.
Select one of the following
Status
Quick Setup
®
MG.20.M2.02 - VLT is a registered Danfoss trademark
6. How to operate the frequency converter
.
Illustration 6.1: Numerical LCP (NLCP)
Illustration 6.2: Status display example
Display
Illustration 6.3: Alarm display example
• Main Menu
Main Menu
Enabled
[1] or
