2. Parameter Description
16-32 Brake Energy /s
Range:
0.000k
2 *
W
16-33 Brake Energy /2 min
Range:
0.000k
*
W
16-34 Heatsink Temp.
Range:
0°C
16-35 Inverter Thermal
Range:
0 %
16-36 Inv. Nom. Current
Range:
*
A
16-37 nv. Max. Current
Range:
*
A
16-38 SL Controller State
Range:
*
0
16-39 Control Card Temp.
Range:
0°C
16-40 Logging Buffer Full
Option:
[0]
164
[0.000 - 0.000 kW]
[0.000 - 500.000 kW] View the brake power transmitted to an external brake resistor.
* [0 - 255 °C]
* [0 - 100 %]
[0.01 - 10000 A]
[0.01 - 10000 A]
[0 - 0]
* [0 - 100 °C]
* No
MG.20.O2.02 - VLT
Function:
View the brake power transmitted to an external brake resistor,
stated as an instantaneous value.
Function:
The mean power is calculated on an average basis for the most
recent 120 seconds.
Function:
View the frequency converter heatsink temperature. The cut-
out limit is 90 ± 5 °C, and the motor cuts back in at 60 ± 5 °C.
Function:
View the percentage load on the inverter.
Function:
View the inverter nominal current, which should match the
nameplate data on the connected motor. The data are used for
calculation of torque, motor protection, etc.
Function:
View the inverter maximum current, which should match the
nameplate data on the connected motor. The data are used for
calculation of torque, motor protection, etc.
Function:
View the state of the event under execution by the SL controller.
Function:
View the temperature on the control card, stated in °C.
