VLT AQUA Drive Programming Guide
26-35 Terminal X42/5 High Ref./feedb. Value
Range:
100.000
*
Unit
26-36 Terminal X42/5 Filter Time Constant
Range:
0.001 s
26-37 Terminal X42/5 Live Zero
Option:
[0]
[1]
26-40 Terminal X42/7 Output
Option:
[0]
[100]
[101]
[102]
[103]
[104]
[105]
[106]
[107]
[108]
[113]
[114]
[115]
[139]
[141]
26-41 Terminal X42/7 Output Min. Scale
Range:
*
0%
Function:
[Par. 26-34 - Enter the analog input scaling value that corresponds to the high
1000000.000] voltage value set in par 26-21.
Function:
* [0.001 - 10.000 s] Enter the time constant. This is a first-order digital low pass filter
time constant for suppressing noise in terminal X42/5. A high
time constant value improves dampening but also increases the
time delay through the filter. This parameter cannot be adjusted
while the motor is running.
Function:
Disabled
Enabled This parameter makes it possible to enable the Live Zero mon-
itoring. E.g. where the analog input is a part of the frequency
converter control, rather than being used as part of a decentral
I/O system, such as a Building Management System.
Function:
Set the function of terminal X42/7 as an analog current output.
No operation
Output frequency
Reference
Feedback
Motor current
Torque rel to lim.
Torque rel to rated
Power
Speed
Torque
Ext. Closed Loop 1
Ext. Closed Loop 2
Ext. Closed Loop 3
Bus ctrl.
Bus ctrl timeout
Function:
[0.00 - 200%] Scale the minimum output of the selected analog signal at ter-
®
