2.8.9. 6-6* Analog Output 2 (MCB 101)
Analog outputs are current outputs: 0/4 - 20 mA. Common terminal (terminal X30/7) is the same
terminal and electrical potential for analog common connection. Resolution on analog output is
12 bit.
6-60 Terminal X30/8 Output
Option:
*
[0]
[100]
[101]
[102]
[103]
[104]
[105]
[106]
[107]
[108]
[113]
[114]
[115]
[130]
[131]
[132]
[133]
[134]
[135]
[136]
[137]
[138]
[139]
[140]
[141]
[142]
[143]
[144]
[145]
6-61 Term. X30/8 Output Min Scale
Range:
*
0%
Function:
No operation
Output frequency
Reference
Feedback
Motor Current
Torque re. to lim.
Torque rel. to rated
Power
Speed
Torque
Ext. Closed Loop 1
Ext. Closed Loop 2
Ext. Closed Loop 3
Output freq. 4-20 mA
Reference 4-20 mA
Feedback 4-20 mA
Motor cur. 4-20 mA
Torq. % lim 4-20 mA
Torq. % nom 4-20 mA
Power 4-20 mA
Speed 4-20 mA
Torque 4-20 mA
Bus Ctrl 0-20 mA
Bus Ctrl 4-20 mA
Bus Ctrl timeout 0-20
mA
Bus Ctrl timeout 4-20
mA
Ext. Closed Loop 1
4-20 mA
Ext. Closed Loop 2
4-20 mA
Ext. Closed Loop 3
4-20 mA
Function:
[0.00 - 200 %] Scales the minimum output of the selected analog signal on ter-
minal X30/8. Scale the minimum value as a percentage of the
®
