2. Parameter Description
16-72 Counter A
Range:
*
0
2
16-73 Counter B
Range:
*
0
16-74 Precise Stop Counter
Range:
*
0
16-75 Analog In X30/11
Range:
0.000
16-76 Analog In X30/12
Range:
0.000
16-77 Analog Out X30/8 16-77 [mA]
Range:
0.000
2.15.7. 16-8* Fieldbus & FC Port
Parameters for reporting the BUS references and control words.
16-80 Fieldbus CTW 1
Range:
*
0
168
Function:
[0 - 0] View the present value of Counter A. Counters are useful as
comparator operands, see par. 13-10.
The value can be reset or changed either via digital inputs (pa-
rameter group 5-1*) or by using an SLC action (par. 13-52).
Function:
[0 - 0] View the present value of Counter B. Counters are useful as
comparator operands (par. 13-10).
The value can be reset or changed either via digital inputs (pa-
rameter group 5-1*) or by using an SLC action (par. 13-52).
Function:
[-2147483648 - Returns the actual counter value of precise counter (par. 1-84).
2147483648]
Function:
*
[0.000 - 0.000] View the actual value at input X30/11 of MCB 101.
Function:
*
[0.000 - 0.000] View the actual value at input X30/12 of MCB 101.
Function:
* [0.000 - 0.000] View the actual value at input X30/8 in mA.
Function:
[0 - 65535] View the two-byte Control word (CTW) received from the Bus-
Master. Interpretation of the Control word depends on the
fieldbus option installed and the Control word profile selected in
par. 8-10.
For more information please refer to the relevant fieldbus man-
ual.
