2. Parameter Description
2
[0]
[1]
[2]
[3]
[4]
[5]
[10]
[11]
[12]
[13]
[14]
[15]
[16]
[17]
[18]
[19]
[22]
[23]
[24]
[26]
[27]
[28]
[29]
[30]
[31]
[32]
142
*
Disabled
No action
Select set-up 1
Select set-up 2
Select set-up 3
Select set-up 4
Select preset refer-
ence 0
Select preset refer-
ence 1
Select preset refer-
ence 2
Select preset refer-
ence 3
Select preset refer-
ence 4
Select preset refer-
ence 5
Select preset refer-
ence 6
Select preset refer-
ence 7
Select ramp 1
Select ramp 2
Run
Run reverse
Stop
Dcstop
Coast
Freeze output
Start timer 0
Start timer 1
Start timer 2
Set digital output A
low
MG.20.O2.02 - VLT
Select the action corresponding to the SLC event. Actions are
executed when the corresponding event (defined in par. 13-51)
is evaluated as true. The following actions are available for se-
lection:
Changes the active set-up (par. 0-10) to '1'.
Changes the active set-up (par. 0-10) to '2'.
Changes the active set-up (par. 0-10) to '3'.
Changes the active set-up (par. 0-10) to '4'. If the set-up is
changed, it will merge with other set-up commands coming
from either the digital inputs or via a fieldbus.
Selects preset reference 0.
Selects preset reference 1.
Selects preset reference 2.
Selects preset reference 3.
Selects preset reference 4.
Selects preset reference 5.
Selects preset reference 6.
Selects preset reference 7. If the active preset reference is
changed, it will merge with other preset reference commands
coming from either the digital inputs or via a fieldbus.
Selects ramp 1
Selects ramp 2
issues a start command to the frequency converter.
Issues a start reverse command to the frequency converter.
Issues a stop command to the frequency converter.
Issues a DC stop command to the frequency converter.
The frequency converter coasts immediately. All stop com-
mands including the coast command stop the SLC.
Freezes the output frequency of the frequency converter.
Starts timer 0, see par. 13-20 for further description.
Starts timer 1, see par. 13-20 for further description.
Starts timer 2, see par. 13-20 for further description.
Any output with 'digital output 1' selected is low (off).
®
is a registered Danfoss trademark
®
VLT
AQUA Drive Programming Guide
