2. Parameter Description
6-22 Terminal 54 Low Current
Range:
4 mA
2
6-23 Terminal 54 High Current
Range:
20.0
mA
6-24 Terminal 54 Low Ref./Feedb. Value
Range:
0.000
Unit
6-25 Terminal 54 high ref./feedb. value
Range:
100.000
Unit
6-26 Terminal 54 Filter Time Constant
Range:
0.001s
6-27 Terminal 54 Live Zero
Option:
[0]
[1]
2.8.6. 6-3* Analog Input 3 (MCB 101)
Parameter group for configuring the scale and limits for analog input 3 (X30/11) placed on option
module MCB 101.
100
* [0.0 to par. 6-23 mA] Enter the low current value. This reference signal should corre-
[Par. 6-22 to - 20.0
* mA]
[-1000000.000 to par.
* 6-25]
[Par. 6-24 to
*
1000000.000]
* [0.001 - 10.000 s]
Disabled
* Enabled
MG.20.O2.02 - VLT
Function:
spond to the low reference/feedback value, set in par. 6-24. The
value must be set at >2 mA in order to activate the Live Zero
Time-out Function in par. 6-01.
Function:
Enter the high current value corresponding to the high refer-
ence/feedback value set in par. 6-25.
Function:
Enter the analog input scaling value that corresponds to the low
voltage/low current value set in par. 6-20/6-22.
Function:
Enter the analog input scaling value that corresponds to the high
voltage/high current value set in par. 6-21/6-23.
Function:
Enter the time constant. This is a first-order digital low pass filter
time constant for suppressing electrical noise in terminal 54. A
high time constant value improves dampening but also increa-
ses the time delay through the filter.
This parameter cannot be adjusted while the motor is running.
Function:
This parameter makes it possible to disable the Live Zero mon-
itoring. E.g. to be used if the analog outputs are used as part of
a decentral I/O system (e.g. when not part of any frequency
converter related control functions, but feeding an external con-
trol system with data)
®
