Danfoss VLT AQUA Programming Manual page 73

®
VLT AQUA Drive Programming Guide
4-51 Warning Current High
Range:
par.
16-37
*
A
4-52 Warning Speed Low
Range:
0 RPM
4-53 Warning Speed High
Range:
par.
4-13
*
RPM
4-54 Warning Reference Low
Range:
-999999
*
.999
4-55 Warning Reference High
Range:
999999.
*
999
27 or 29 and on relay output 01 or 02. Refer to the drawing in
this section.
Function:
[Par. 4-50 - par. Enter the I
16-37 A] (I
HIGH
can be programmed to produce a status signal on terminal 27
or 29 and on relay output 01 or 02. Refer to the drawing in this
section.
Function:
* [0 - par. 4-53 RPM] Enter the n
limit (n
can be programmed to produce a status signal on terminal 27
or 29 and on relay output 01 or 02. Programme the lower signal
limit of the motor speed, n
of the frequency converter. Refer to the drawing in this section.
Function:
[Par. 4-52 - par. 4-13 Enter the n
RPM]
(n
HIGH
be programmed to produce a status signal on terminal 27 or 29
and on relay output 01 or 02. Programme the upper signal limit
of the motor speed, n
the frequency converter. Refer to the drawing in this section.
Function:
[-999999.999 - Enter the lower reference limit. When the actual reference falls
999999.999] below this limit, the display indicates Ref Low. The signal out-
puts can be programmed to produce a status signal on terminal
27 or 29 and on relay output 01 or 02.
Function:
[-999999.999 - Enter the upper reference limit. When the actual reference ex-
999999.999] ceeds this limit, the display reads Ref High. The signal outputs
can be programmed to produce a status signal on terminal 27
or 29 and on relay output 01 or 02.
®
MG.20.O2.02 - VLT is a registered Danfoss trademark
value. When the motor current exceeds this limit
HIGH
), the display reads CURRENT HIGH. The signal outputs
value. When the motor speed falls below this
LOW
) the display reads SPEED LOW. The signal outputs
LOW
, within the normal working range
LOW
value. When the motor speed exceeds this limit
HIGH
), the display reads SPEED HIGH. The signal outputs can
, within the normal working range of
HIGH
2. Parameter Description
73
2
