1-93 Thermistor Source
Option:
*
[0]
[1]
[2]
[3]
[4]
[5]
[6]

2.4. Main Menu - Brakes - Group 2

2.4.1. 2-0* DC-Brakes
Parameter group for configuring the DC brake and DC hold functions.
2-00 DC Hold Current/Preheat Current
Range:
50 %
2-01 DC Brake Current
Range:
*
50%
Function:
Select the input to which the thermistor (PTC sensor) should be
connected. An analog input option [1] or [2] cannot be selected
if the analog input is already in use as a reference source (se-
lected in par. 3-15
2 or 3-17 Reference Source 3).
This parameter cannot be adjusted while the motor is running.
None
Analog input 53
Analog input 54
Digital input 18
Digital input 19
Digital input 32
Digital input 33
Function:
* [0 - 100%] Enter a value for holding current as a percentage of the rated
motor current I
holding current corresponds to I
This parameter holds the motor function (holding torque) or
pre-heats the motor.
This parameter is active if
tion at Stop
NB!
The maximum value depends on the rated motor current.
NB!
Avoid 100 % current for too long. It may damage the motor.
Function:
[0 - 100 %] Enter a value for current as a percentage of the rated motor
current I
current corresponds to I
DC brake current is applied on a stop command, when the speed
is lower than the limit set in par. 2-03
when the DC Brake Inverse function is active; or via the serial
®
MG.20.O2.02 - VLT is a registered Danfoss trademark
Reference Source
1, 3-16
set in par. 1-24 Motor Current. 100% DC
M,N
.
M,N
DC hold
is selected in par. 1-80
.
, see par. 1-24 Motor Current
M,N
.
M,N
2. Parameter Description
Reference Source
Func-
. 100% DC braking
DC Brake Cut In Speed
;
2
57
