VLT AQUA Drive Programming Guide
[1]
2.15.5. 16-5* Ref. & Feedb.
Parameters for reporting the reference and feedback input.
16-50 External Reference
Range:
*
0.0
16-52 Feedback [Unit]
Range:
*
0.0
16-53 Digi Pot Reference
Range:
0.0
16-54 Feedback 1 [Unit]
Range:
16-55 Feedback 2 [Unit]
Range:
16-56 Feedback 3[Unit]
Range:
Yes View whether the logging buffer is full (see par. 15-1*). The
logging buffer will never be full when par. 15-13
Mode
Function:
[0.0 - 0.0 ] View the total reference, the sum of digital, analog, preset, bus
and freeze references, plus catch-up and slow-down.
Function:
[0.0 - 0.0] View value of resulting feedback value after processing of Feed-
back 1-3 (see par. 16-54, 16-55 and 16-56) in the feedback
manager.
See par. 20-0*
The value is limited by settings in par. 3-02 and 3-03. Units as
set in par. 20-12.
Function:
[0.0 - 0.0] View the contribution of the Digital Potentiometer to the actual
reference.
Function:
[0.0 - 0.0] View value of Feedback 1, see par. 20-0*
Value is limited by settings in par. 3-02 and 3-03. Units as set
in par. 20-12.
Function:
[0.0 - 0.0] View value of Feedback 2, see par. 20-0*
Value is limited by settings in par. 3-02 and 3-03. Units as set
in par. 20-12.
Function:
[0.0 - 0.0] View value of Feedback 3, see par. 20-0*
Value is limited by settings in par. 3-02 and 3-03. Units as set
in par. 20-12.
®
MG.20.O2.02 - VLT is a registered Danfoss trademark
Log always
is set to [0].
Feedback
.
2. Parameter Description
Logging
Feedback .
Feedback
.
Feedback
.
