VLT AQUA Drive Programming Guide
[16]
[17]
[18]
[19]
[20]
[21]
[22]
[23]
[24]
[25]
[26]
[27]
[28]
[29]
[30]
[31]
[32]
[33]
[34]
[35]
[36]
[37]
[38]
[39]
[40]
[41]
[42]
[43]
[44]
[45]
[46]
[47]
Thermal warning See parameter group 5-3* for further description.
Mains out of range See parameter group 5-3* for further description.
Reversing See parameter group 5-3* for further description.
Warning See parameter group 5-3* for further description.
Alarm (trip) See parameter group 5-3* for further description.
Alarm (trip lock) See parameter group 5-3* for further description.
Comparator 0 Use the result of comparator 0 in the logic rule.
Comparator 1 Use the result of comparator 1 in the logic rule.
Comparator 2 Use the result of comparator 2 in the logic rule.
Comparator 3 Use the result of comparator 3 in the logic rule.
Logic rule 0 Use the result of logic rule 0 in the logic rule.
Logic rule 1 Use the result of logic rule 1 in the logic rule.
Logic rule 2 Use the result of logic rule 2 in the logic rule.
Logic rule 3 Use the result of logic rule 3 in the logic rule.
SL Time-out 0 Use the result of timer 0 in the logic rule.
SL Time-out 1 Use the result of timer 1 in the logic rule.
SL Time-out 2 Use the result of timer 2 in the logic rule.
Digital input DI18 Use the value of DI18 in the logic rule (High = TRUE).
Digital input DI19 Use the value of DI19 in the logic rule (High = TRUE).
Digital input DI27 Use the value of DI27 in the logic rule (High = TRUE).
Digital input DI29 Use the value of DI29 in the logic rule (High = TRUE).
Digital input DI32 Use the value of DI32 in the logic rule (High = TRUE).
Digital input DI33 Use the value of DI33 in the logic rule (High = TRUE).
Start command This event is TRUE if the frequency converter is started by any
means (either via digital input, field bus or other).
Drive Stopped This event is TRUE if the frequency converter is stopped or
coasted by any means (either via digital input, fieldbus or other).
Reset Trip This event is TRUE if the frequency converter is tripped (but not
trip-locked) and the reset button is pressed.
Auto Reset Trip This event is TRUE if the frequency converter is tripped (but not
trip-locked) and an Automatic Reset is issued.
OK Key This event is TRUE if the OK key on the LCP is pressed.
Reset Key This event is TRUE if the Reset key on the LCP is pressed.
Left Key This event is TRUE if the Left key on the LCP is pressed.
Right Key This event is TRUE if the Right key on the LCP is pressed.
Up Key This event is TRUE if the Up key on the LCP is pressed.
®
