7 How to operate the adjustable frequency
drive
[Reset]
is used for resetting the adjustable frequency drive after an alarm (trip). The key can be
The parameter shortcut
can be carried out by holding down the [Main Menu] key for 3 seconds. The parameter shortcut allows direct access to any parameter.

7.1.3 How to operate the numeric LCP (NLCP)

The following instructions are valid for the NLCP (LCP 101).
The control panel is divided into four functional groups:
1. Numeric display.
2. Menu key and LEDs - changing parameters and switching be-
tween display functions.
3. Navigation keys and LEDs.
4. Operation keys and LEDs.
NOTE!
Parameter copy is not possible with the Numeric Local
7
Control Panel (LCP101).
Select one of the following modes:
Status Mode: Displays the status of the adjustable frequency drive or
the motor.
If an alarm occurs, the NLCP automatically switches to status mode.
A number of alarms can be displayed.
Quick Set-up or Main Menu Mode:
settings.
LEDs:
• Green LED/On: Indicates whether control section is on.
• Yellow LED/Wrn.: Indicates a warning.
• Flashing red LED/Alarm: Indicates an alarm.
Menu key
[Menu] Select one of the following modes:
• Status
• Quick Set-up
• Main Menu
Main Menu
is used for programming all parameters.
7-6
Display parameters and parameter
MG.20.M5.22 - VLT
Enabled Disabled
[1] or [0] via par. 0-43
Figure 7.1: Numerical LCP (NLCP)
Figure 7.2: Status display example
Figure 7.3: Alarm display example
®
is a registered Danfoss trademark
®
VLT AQUA Drive
Instruction Manual
Reset Keys on LCP
.
