2. Parameter Description
[16-76] Analog In X30/12
[16-77] Analog In X30/8 [mA]
[16-84] Comm Option STW
2
[16-85] FC port CTW 1
[16-90] Alarm Word
[16-91] Alarm Word 2
[16-92] Warning Word
[16-93] Warning Word 2
[16-94] Extended
[16-95] Extended
[16-96] Prev.
9-18 Node Address
Range:
126
9-22 Telegram Selection
Option:
[1]
[101]
[102]
[103]
[104]
[105]
[106]
[107]
[108]
9-23 Parameters for Signals
Array [1000]
[3-02]
118
Status
Word
Status
Word 2
Maintenance
Word
* [0 - 126]
Standard telegram 1
PPO 1
PPO 2
PPO 3
PPO 4
PPO 5
PPO 6
PPO 7
* PPO 8
None
Minimum Reference
MG.20.O2.02 - VLT
Function:
Enter the station address in this parameter or alternatively in
the hardware switch. In order to adjust the station address in
par. 9-18, the hardware switch must be set to 126 or 127 (i.e.
all switches set to 'on'). Otherwise this parameter will display
the actual setting of the switch.
Function:
Select a standard Profibus telegram configuration for the fre-
quency converter, as an alternative to using the freely configu-
rable telegrams in par. 9-15 and 9-16.
This parameter contains a list of signals available for selection
in par. 9-15 and 9-16.
®
