VLT AQUA Drive Programming Guide
0-22 Display Line 1.3 Small
Option:
[1614]
0-23 Display Line 2 Large
Option:
[1615]
0-24 Display Line 3 Large
Option:
[1652]
0-25 My Personal Menu
Array [20]
2.2.5. LCP Custom Readout, Par. 0-3*
It is possible to customize the display elements for various purposes: *Custom Readout. Value
proportional to speed (Linear, squared or cubed depending on unit selected in par. 0-30
Readout Unit
Custom Readout
The calculated value to be displayed is based on settings in par. 0-30,
Custom Readout Min Value
0-31
4-13/4-14,
Function:
Select a variable for display in line 1, right position.
* Motor Current The options are the same as those listed for par. 0-20
Line 1.1 Small
Function:
Select a variable for display in line 2. The options are the same
as those listed for par. 0-20
* Frequency
Function:
* Feedback [Unit] Select a variable for display in line 2. The options are the same
as those listed for par. 0-20
[0 - 9999] Define up to 50 parameters to appear in the Q1 Personal Menu,
accessible via the [Quick Menu] key on the LCP. The parameters
will be displayed in the Q1 Personal Menu in the order they are
programmed into this array parameter. Delete parameters by
setting the value to '0000'.
For example, this can be used to provide quick, simple access
to just one or up to 20 parameters which require changing on a
regular basis (e.g. for plant maintenance reasons) or by an OEM
to enable simple commissioning of their equipment.
) *Display Text. Text string stored in a parameter.
, (linear only), par. 0-32,
Motor Speed High Limit
and actual speed.
®
