VLT AQUA Drive Programming Guide
[33]
[34]
[35]
[36]
[37]
[38]
[39]
[40]
[41]
[42]
[43]
[60]
[61]
[70]
[71]
[72]
[73]
[74]

2.13. Main Menu - Special Functions -Group 14

2.13.1. 14-** Special Functions
Parameter group for configuring special frequency converter functions.
2.13.2. Inverter Switching, 14-0*
Parameters for configuring the inverter switching.
14-00 Switching Pattern
Option:
*
[0]
[1]
Set digital output B Any output with 'digital output 2' selected is low (off).
low
Set digital output C Any output with 'digital output 3' selected is low (off).
low
Set digital output D Any output with 'digital output 4' selected is low (off).
low
Set digital output E Any output with 'digital output 5' selected is low (off).
low
Set digital output F Any output with 'digital output 6' selected is low (off).
low
Set digital output A Any output with 'digital output 1' selected is high (closed).
high
Set digital output B Any output with 'digital output 2' selected is high (closed).
high
Set digital output C Any output with 'digital output 3' selected is high (closed).
high
Set digital output D Any output with 'digital output 4' selected is high (closed).
high
Set digital output E Any output with 'digital output 5' selected is high (closed).
high
Set digital output F Any output with 'digital output 6' selected is high (closed).
high
Reset Counter A Resets Counter A to zero.
Reset Counter B Resets Counter A to zero.
Start Timer 3 Starts timer 3, see par. 13-20 for further description.
Start Timer 4 Starts timer 4, see par. 13-20 for further description.
Start Timer 5 Starts timer 5, see par. 13-20 for further description.
Start Timer 6 Starts timer 6, see par. 13-20 for further description.
Start Timer 7 Starts timer 7, see par. 13-20 for further description.
Function:
60 AVM
SFAVM Select the switching pattern: 60° AVM or SFAVM.
®
MG.20.O2.02 - VLT is a registered Danfoss trademark
2. Parameter Description
143
2
