VLT
AQUA Drive Design Guide
Contents
1 How to Read this Design Guide
Copyright, Limitation of Liability and Revision Rights
Symbols
Abbreviations
Definitions
2 Introduction to the VLT AQUA Drive
CE labeling
Vibration and shock
Control Structures
General aspects of EMC
Immunity Requirements
Galvanic isolation (PELV)
PELV - Protective Extra Low Voltage
Ground leakage current
Control with brake function
Control with Brake Function
Mechanical brake control
Extreme running conditions
Safe Stop Operation (optional)
3 VLT AQUA Selection
General Specifications
Efficiency
Special Conditions
Options and Accessories
General Description
High Power Options
Installation of Duct Cooling Kit in Rittal Enclosures
Outside Installation/ NEMA 3R Kit for Rittal enclosures
Installation on Pedestal
Input Plate Option
Installation of Line Power Shield for Adjustable Frequency Drives
Frame size F Panel Options
4 How to Order
Ordering form
Type Code String
®
MG.20.N5.22 - VLT
is a registered Danfoss trademark
Contents
1-1
1-1
1-2
1-3
1-3
2-1
2-3
2-6
2-11
2-20
2-24
2-25
2-25
2-26
2-27
2-28
2-28
2-28
2-32
3-1
3-1
3-19
3-25
3-31
3-40
3-47
3-47
3-49
3-51
3-53
3-54
3-55
4-1
4-1
4-2
