Texas Instruments TMS320C3x User Manual page 632

NEGF
Negate Floating-Point Value
Syntax
Operation
Operands
Opcode
Description
Cycles
Status Bits
Mode Bit
13-174
NEGF src, dst
0 – src dst
src general addressing modes (G):
0 0 register (R n , 0
0 1 direct
1 0 indirect (disp = 0–255, IR0, IR1)
1 1 immediate
dst register (R n , 0 n
31 24 23
0 0 0 0 1 0 1 1 1
The difference of the 0 and src operands is loaded into the dst register. The
dst and src operands are assumed to be floating-point numbers.
1
These condition flags are modified only if the destination register is R7 – R0.
LUF 1 if a floating-point underflow occurs; unchanged otherwise
LV 1 if a floating-point overflow occurs; unchanged otherwise
UF 1 if a floating-point underflow occurs; 0 otherwise
N 1 if a negative result is generated; 0 otherwise
Z 1 if a 0 result is generated; 0 otherwise
V 1 if a floating-point overflow occurs; 0 otherwise
C Unaffected
OVM Operation is affected by OVM bit value.
n 7)
7)
16 15
G dst
8 7 0
src
