Syntax
Operation
Operands
Opcode
Description
Cycles
Status Bits
Mode Bit
MPYI3 src2, src1, dst
src1 src2 dst
src1 3-operand addressing modes (T):
0 0 any CPU register
0 1 indirect ( disp = 0, 1, IR0, IR1)
1 0 any CPU register
1 1 indirect ( disp = 0, 1, IR0, IR1)
src2 3-operand addressing modes (T):
0 0 any CPU register
0 1 any CPU register
1 0 indirect ( disp = 0, 1, IR0, IR1)
1 1 indirect ( disp = 0, 1, IR0, IR1)
dst register (R n , 0
31 24 23
0 0 1 0 0 1 0 1 0
The product of the src1 and src2 operands is loaded into the dst register. The
src1 and src2 operands are assumed to be 24-bit signed integers. The result
is assumed to be a signed 48-bit integer. The output to the dst register is the
32 LSBs of the result.
Integer overflow occurs when any of the 16 MSBs of the 48-bit result differs
from the MSB of the 32-bit output value.
1
These condition flags are modified only if the destination register is R7 – R0.
LUF Unaffected
LV 1 if an integer overflow occurs; unchanged otherwise
UF 0
N 1 if a negative result is generated; 0 otherwise
Z 1 if a 0 result is generated; 0 otherwise
V 1 if an integer overflow occurs; 0 otherwise
C Unaffected
OVM Operation is affected by OVM bit value.
Multiply Integer, 3-Operand
n
27)
16 15
T dst
Assembly Language Instructions
8 7
src 1 src 2
MPYI3
0
13-161
