Output Bin Full - Xerox Phaser 3330 Service Manual

Output Bin Full

The Output Bin Full Sensor detected that the tray is 90% full.
Applicable Error
• 08-700: Output Bin full
Initial Actions
• Clear the output bin of paper.
• If problem persists use the following procedure.
Troubleshooting Reference Table
Applicable Parts
• Out-bin Full Sensor (PL 3.1.20,
3.1 Frame (1 of 2))
• Main PWB: Phaser 3330 (PL 1.0.7,
List 1.0 Phaser 3330
3335 and 3345 (PL 6.1.7,
WorkCentre 3335/3345
Troubleshooting Procedure Table
Step Actions and Questions
1. Enter dC330 Component
08-720 to check the Out-bin Full Sensor.
The display changes when the sensor is
actuated?
2. Re-seat CN2 on the Main PWB.
Does the error persist?
Xerox Internal Use Only
Wiring and Plug/Jack Map Reference
Parts List • Phaser 3330 Main PWB Connector Designators
• Phaser 3330 Control Panel PWB
Parts
• Wiring Diagrams for P3330/WC3335/WC3345
Main), WorkCentre
• WorkCentre 3335/3345 Main PWB Connector Designators
Parts List 6.1
• DADF PWB
Main).
• SMPS PWB
Control, code
Yes
Go to step 3.
Go to step 3.
Phaser 3330 and WorkCentre 3335/3345
Troubleshooting
No
Replace the Out-bin Full
Sensor (PL 3.1.20, Parts
List 3.1 Frame (1 of 2))
Note: Refer to the sensor
actuator to identify the
specific sensor.
• 3330 Out-bin Full
Actuator (PL 1.1.9,
Parts List 1.1 Phaser
3330 Top Cover)
• 3335/3345 Out-bin
Full Actuator (PL
6.2.6, Parts List 6.2
WorkCentre
3335/3345 Middle
Cover)
Continue with step 2.
Complete.
2-59
Service Manual
