3. Commissioning

3.5.2 Commissioning of the motor controllers

Festo P.BE−CPX−CM−HPP−EN en 0910NH
Note
Carry out the following instructions for each motor
controller.
1. Connect the PC and the motor controller with a serial
programming cable.
2. Start the FCT software and follow the instructions in the
FCT and in the operating instructions of the respective
motor controller.
3. Make sure that the limit switches work properly
4. Check the following parameters
Maximum travel distances
Maximum travel speed
Maximum acceleration or deceleration
Translation factor for position and speed
Software limit switch
Type of homing
5. Edit the positioning record table if you want to operate
the drive in the record selection mode
6. Save your settings in the controller (download −> save)
and in the project (save)
The subsequent chapters describe the specific parameters
for the respective drives for operation with CPX−CM−HPP.
3−13
