Ec-1200 Cabinet - EMC Connectrix EC-1200 Planning Manual

Specifications
F
Specifications

EC-1200 Cabinet

Characteristics
Connectrix v6.02 Planning Guide
F-2
Physical Dimensions
Weight
Acoustical Noise
Inclination
Fiber Cables Supported
DS-xxMs installable
ED-64Ms installable
ED-140Ms installable
Power
Input power
Requirements
User-supplied Power
Outlets (2)
Input Power Cords (2)
from EC-1200
Auto-call Modem Input
Power
User-supplied Modem
Power Connector
a. EMC previously shipped Russellstoll 3720DP (UL94-5VA, blue housing).
Height: 74 in (188 cm)
Width: 24.25 in (61.6 cm)
Depth: 37 in (94 cm)
Height of service processor shelf: 35 in (89 cm) from floor
EC-1200 with no switches: 400 lbs (183.04 kg)
Packing container: approximately 100 lbs (45.35 kg)
65 dB "A" scale
10° maximum (packaged)
420 maximum
12 maximum per cabinet
4 maximum per cabinet
3 maximum per cabinet
Two 20-Amp dedicated circuits, 208 to 264 VAC, 47 to 63 Hz
Domestic: • Russellstoll 3913
• Russellstoll 9C23U0 (flexible, UL94-VO)
• Russellstoll 3743X
• Russellstoll 9R23U0W (rigid, UL94-VO)
International: Country-specific
Domestic: Russellstoll 9P23U0 (UL94-VO, yellow housing)
International: Country-specific
Domestic: 110 VAC, 15 Amps
International: Country-specific
Domestic: NEMA 5-15R
International: Country-specific
(flexible, aluminum)
(rigid, aluminum)
a
