Device placement requirements

(CX3-10 Class and CX3-20 Class Storage Systems)
This document explains how to install CX3-series hardware in cabinets
that conform to the National Electrical Manufacturer's Association
(NEMA) standards for 19-inch cabinets (in which the left and right
mounting channels are 19 inches apart). It covers mounting hardware
for SPS, SPE3, and DAE3P components, and describes how to cable the
system to AC power and set up the back-end (disk I/O) bus. In most
cases, the illustrations and examples refer to standard cabinets that are
40U tall.
Topics are:
Device placement requirements ......................................................... 1
Device height requirements ................................................................ 5
Power requirements ............................................................................. 4
Setting up an installed storage system ............................................ 28
Note: Instructions for adding switches to a storage system are included in the
device-specific documentation that accompanies the switch.
This document provides the steps required to install rails and enclosures
in both EMC and non-EMC cabinets. Unless otherwise specified, the
illustrations depict the 40U-C cabinet.
Rails and Enclosures
Field Installation Guide
EMC
P/N 300-004-546
REV A03
July 20, 2007
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CX3-10 and is the answer not in the manual?

Questions and answers

Summary of Contents for EMC CX3-10

  • Page 1: Table Of Contents

    Note: Instructions for adding switches to a storage system are included in the device-specific documentation that accompanies the switch. Device placement requirements This document provides the steps required to install rails and enclosures in both EMC and non-EMC cabinets. Unless otherwise specified, the illustrations depict the 40U-C cabinet.
  • Page 2 All of the storage systems and enclosures mentioned in this document have fans or blowers that move air from front to back. EMC Rails and Enclosures (CX3-10 Class and CX3-20 Class Storage Systems) Field Installation Guide...
  • Page 3 (SPE3). In most cases, install that first enclosure (sometimes called the DAE3P-OS, or vault) directly above the standby power supply (SPS). Stack additional DAE3Ps directly above the DAE3P-OS. EMC Rails and Enclosures (CX3-10 Class and CX3-20 Class Storage Systems) Field Installation Guide...
  • Page 4: Power Requirements

    2.2 A @ 200 V AC Note: For high availability, the left and right sides of any rack or cabinet must receive power from separate branch feed circuits. EMC Rails and Enclosures (CX3-10 Class and CX3-20 Class Storage Systems) Field Installation Guide...
  • Page 5: Device Height Requirements

    Device height requirements and cabinet mounting measurements are based on NEMA units (U’s). See Table NEMA unit heights Table 1 Number of U’s Actual height 1-3/4 inches 3-1/2 inches 5-1/4 inches 7 inches EMC Rails and Enclosures (CX3-10 Class and CX3-20 Class Storage Systems) Field Installation Guide...
  • Page 6 SPE3, some switches 2U, 3-1/2 in,90 mm CX3-80 SPS, some switches 3U, 5-1/4 in, 133 mm EMC DAE2P, DAE3P 4U, 7 in, 178 mm CX3-series SPE2 EMC Rails and Enclosures (CX3-10 Class and CX3-20 Class Storage Systems) Field Installation Guide...
  • Page 7 Device height requirements 1U (1.75-in.) Increment EMC2205 U increments in a cabinet front channel Figure 3 EMC Rails and Enclosures (CX3-10 Class and CX3-20 Class Storage Systems) Field Installation Guide...
  • Page 8: Installing A 1U Storage Processor Enclosure (Spe3) In A Cabinet

    1. Locate and unpack the rail kit that accompanied your enclosure. The front edge of each rail is stamped L or R for left and right sides, when they face the cabinet front. EMC Rails and Enclosures (CX3-10 Class and CX3-20 Class Storage Systems) Field Installation Guide...
  • Page 9 Alignment Pin Here EMC292 Figure 4 Aligning pins in a 1U section on the cabinet rear rails EMC Rails and Enclosures (CX3-10 Class and CX3-20 Class Storage Systems) Field Installation Guide...
  • Page 10 Alignment pin Alignment pin Left front Right rear Screw (1) Screw (2) Front Mounting rail Mounting rail Alignment pin EMC3430 Installing the adjustable mounting rails Figure 5 EMC Rails and Enclosures (CX3-10 Class and CX3-20 Class Storage Systems) Field Installation Guide...
  • Page 11 EMC Rails and Enclosures (CX3-10 Class and CX3-20 Class Storage Systems) Field Installation Guide...
  • Page 12 2. Once the enclosure is completely seated into the rear tabs, tighten the two screws (the top one on each rail) that secure the rails to the front channels. EMC Rails and Enclosures (CX3-10 Class and CX3-20 Class Storage Systems) Field Installation Guide...
  • Page 13: Installing A 1U Sps Tray And Sps Units In A Cabinet

    This section explains how to install a 1U SPS (standby power supply) tray in the cabinet. CX3-20 class systems require two 1000w 1U SPS units in a single 1U tray; a second SPS unit is optional in CX3-10 class systems.
  • Page 14 2 latch brackets Secure 1U bezel in 40U cabinets 10 Phillips M5 x 16-mm panhead screws Attach the rail mounting hardware in a (black) 40U cabinet EMC Rails and Enclosures (CX3-10 Class and CX3-20 Class Storage Systems) Field Installation Guide...
  • Page 15 Alignment Pin Here EMC2922 Aligning pins in a 1U section on the cabinet rear rails Figure 8 EMC Rails and Enclosures (CX3-10 Class and CX3-20 Class Storage Systems) Field Installation Guide...
  • Page 16 Screw (2) Front Mounting rail Mounting rail Alignment pin EMC3253 Installing the 1U SPS adjustable rails Figure 9 5. Repeat steps through for the other rail assembly. EMC Rails and Enclosures (CX3-10 Class and CX3-20 Class Storage Systems) Field Installation Guide...
  • Page 17 1. Remove the SPS units from their packaging. 2. Working from the front of the cabinet, slide the SPS units onto the tray as shown in Figure EMC Rails and Enclosures (CX3-10 Class and CX3-20 Class Storage Systems) Field Installation Guide...
  • Page 18 4. Insert and tighten the M4 x 8-mm panhead securing screws that secure the SPS units to the back of the tray, as shown in Figure EMC Rails and Enclosures (CX3-10 Class and CX3-20 Class Storage Systems) Field Installation Guide...
  • Page 19 2. Press the bezel onto the latch brackets until it snaps into place. See Figure Rear Latch Bracket Front Latch Bracket EMC3250 Installing the latch bracket and bezel Figure 12 EMC Rails and Enclosures (CX3-10 Class and CX3-20 Class Storage Systems) Field Installation Guide...
  • Page 20: Installing A 3U Disk Enclosure (Dae3P) In A Cabinet

    19" cabinet EMC3248 12 Phillips M5 12.7 mm screws Attach the rail mounting hardware in a 40U cabinet 3U bezel (front rack panel) with keys EMI shielding EMC Rails and Enclosures (CX3-10 Class and CX3-20 Class Storage Systems) Field Installation Guide...
  • Page 21 6. From the rear of the cabinet, use two of the provided screws to secure each rail to the rear channel. Tighten the screws. EMC Rails and Enclosures (CX3-10 Class and CX3-20 Class Storage Systems) Field Installation Guide...
  • Page 22 EMC2892a Adjustable rail Right rear Right front Screw (2) Screw (2) Alignment pin (2) Mounting rail Mounting rail EMC3452 Installing the adjustable mounting rails Figure 13 EMC Rails and Enclosures (CX3-10 Class and CX3-20 Class Storage Systems) Field Installation Guide...
  • Page 23 Without proper equipment and procedures, you risk damaging disk drives any time you remove, store, or install them. Do not remove disks prior to installing the chassis. EMC Rails and Enclosures (CX3-10 Class and CX3-20 Class Storage Systems) Field Installation Guide...
  • Page 24 EMC Rails and Enclosures (CX3-10 Class and CX3-20 Class Storage Systems) Field Installation Guide...
  • Page 25 If you are installing the enclosure in a NEBS-compliant environment, secure the unit to the front channels with the four shape thread rolling screws supplied with your installation hardware in part number 100-560-644. EMC Rails and Enclosures (CX3-10 Class and CX3-20 Class Storage Systems) Field Installation Guide...
  • Page 26 Figure 17 6. If you are installing another DAE3P in the cabinet, repeat the procedure starting on page 20, stacking additional disk enclosures above the DAE3P-OS. EMC Rails and Enclosures (CX3-10 Class and CX3-20 Class Storage Systems) Field Installation Guide...
  • Page 27 Installing a 3U disk enclosure (DAE3P) in a cabinet Next, set up the DAE3P-OS, SPE3, and SPS units as described in the following sections of this document. EMC Rails and Enclosures (CX3-10 Class and CX3-20 Class Storage Systems) Field Installation Guide...
  • Page 28: Setting Up An Installed Storage System

    LCC A EA2/Bus 0 EA1/Bus 0 EA0/Bus 0 Bus 0 Bus 0 SP B SP A CL3710 Figure 18 Connecting the SPE3 to the first DAE3P EMC Rails and Enclosures (CX3-10 Class and CX3-20 Class Storage Systems) Field Installation Guide...
  • Page 29 Note: If your system includes additional DAE3P enclosures, do NOT connect them to the back-end bus at this time. You will assign enclosure addresses and complete DAE3P-to-DAE3P cabling in a later step. EMC Rails and Enclosures (CX3-10 Class and CX3-20 Class Storage Systems) Field Installation Guide...
  • Page 30: Connecting Ac Power

    The strain reliefs prevent the power cord from pulling out of the connections. Generic Plug Retention Bail Retention Bail Generic EMC3213 Plug Plugging in the AC line cords Figure 20 EMC Rails and Enclosures (CX3-10 Class and CX3-20 Class Storage Systems) Field Installation Guide...
  • Page 31 Note: If your system includes additional DAE3P enclosures, do NOT connect them to AC power sources at this time. You will complete DAE3P cabling in a later step. EMC Rails and Enclosures (CX3-10 Class and CX3-20 Class Storage Systems) Field Installation Guide...
  • Page 32 Setting up an installed storage system Power source B Power source A CL3711 Connecting CX3-10 class power cords (single SPS) Figure 21 EMC Rails and Enclosures (CX3-10 Class and CX3-20 Class Storage Systems) Field Installation Guide...
  • Page 33: What Next

    Connecting CX3-10/20 class power cords (dual SPS) What Next? Continue with Install, Step 2, "Power up," in your Interactive Installation Guide CD or CX3-series Setup Guide. EMC Rails and Enclosures (CX3-10 Class and CX3-20 Class Storage Systems) Field Installation Guide...
  • Page 34 What Next? Copyright © 2007 EMC Corporation. All rights reserved. EMC believes the information in this publication is accurate as of its publication date. The information is subject to change without notice. THE INFORMATION IN THIS PUBLICATION IS PROVIDED “AS IS.” EMC CORPORATION...
