Switch# configure terminal
Switch (config)# mep 1 ais fr1s
mep <Instance> aps
Command:
mep <Instance> aps <prio> [ multi | uni ] { laps | { raps [ octet
<octet> ] } }
mep Maintenance Entity Point
<Instance> The MEP instance number.
aps Automatic Protection Switching protocol
laps Linear Automatic Protection Switching protocol.
multi OAM PDU is transmitted with multicast MAC. Must me 'multi' in case of
uni OAM PDU is transmitted with unicast MAC. The MAC is taken from peer
MEP MAC database. Only possible in case of LAPS.
raps Ring Automatic Protection Switching protocol.
octet Then last OCTET in the multicast MAC. Only possible in case of RAPS.
<Octet : uint>
uni OAM PDU is transmitted with unicast MAC. The MAC is taken from peer
MEP MAC database. Only possible in case of LAPS.
Default:
None
Usage Guide:
To configure APS of MEP
Example:
To configure APS of MEP 1 as below table
Switch# configure terminal
Switch (config)# mep 1 aps 7 laps
mep <Instance> cc
Command:
mep <Instance> cc <Prio : 0-7> fr100s | fr10s | fr1m | fr1s |
fr300s | fr6h | fr6m
mep Maintenance Entity Point
<Instance> The MEP instance number.
cc Continuity Check
<Prio : 0-7>
NS4750-24S-4T-4X-V2 Managed Switch Command Guide
RAPS.
Last OCTET value
Priority in case of tagged OAM. In the EVC domain this is the COS-
ID.
