mep Maintenance Entity Point
<Instance> The MEP instance number.
level The MEG level on the client layer
<Level : 0-7>
ais-prio AIS injection priority
<Aisprio : 0-7>
ais-highest
lck-prio LCK injection priority
<Lckprio : 0-7>
lck-highest
Default:
0
Usage Guide:
To configure Client Flow of MEP
Example:
To configure Client Flow of MEP 1 as below table.
Switch# configure terminal
Switch (config)# mep 1 client flow 5 level 4 ais-prio ais-highest
lck-prio 3
mep <Instance> dm
Command:
mep <Instance> dm <prio> [ multi | { uni mep-id <mepid> } ]
[ single | dual ] [ rdtrp | flow ] interval <interval> last-n <lastn>
mep Maintenance Entity Point
<Instance> The MEP instance number.
dm Delay Measurement
<Prio : 0-7>
dual Delay Measurement based on 1DM PDU transmission.
flow The two way delay is calculated as round trip symmetrical flow delay. The
interval Interval between PDU transmission in 10ms. Min value is 10.
<Interval : uint>
multi OAM PDU is transmitted with multicast MAC.
rdtrp The two way delay is calculated as round trip delay. The far end residence
time is not subtracted.
single Delay Measurement based on DMM/DMR PDU.
uni OAM PDU is transmitted with unicast MAC. The MAC is taken from peer
MEP MAC database.
mep-id Peer MEP-ID for unicast DM. The MAC is taken from peer MEP MAC
database.
NS4750-24S-4T-4X-V2 Managed Switch Command Guide
The MEG level value
AIS injection priority value
Request the highest possible AIS priority
LCK injection priority value.
Request the highest possible LCK priority.
Priority in case of tagged OAM. In the EVC domain this is the
COS-ID
far end residence time is subtracted.
Interval value
