Parameters

3.4 Main Menu - Reference/Ramps - Group

3
3.4.1 3-0* Reference Limits
3 3
Parameters for setting the reference unit, limits and ranges.
Also see parameter group 20-0* Feedback for information
on settings in closed loop.
3-02 Minimum Reference
Range:
0 ReferenceFeed-
backUnit
*
3-03 Maximum Reference
Range:
Size
related ReferenceFeed-
*
backUnit]
3.4.2 3-1* References
P3-03
P3-02
0
Illustration 3.4 References
32
Function:
[ -4999.0 - 4999 The Minimum
ReferenceFeed- Reference is the
backUnit] lowest value
obtainable by
summing all
references.
Function:
[ -4999.0 - 4999 The maximum reference is the
highest value obtainable by
summing all references. The
maximum reference unit
matches the choice of configu-
ration in 1-00 Configuration
Mode.
50
®
VLT HVAC Basic Drive FC 101 Programming Guide
3-10 Preset Reference
Range:
0 %
*
100 %]
3-11 Jog Speed [Hz]
Range:
5 Hz
*
Hz]
3-14 Preset Relative Reference
Range:
0 [-100
% - 100
*
%]
3-15 Reference 1 Source
Option:
[0] No function
[1] Analog in 53
*
[2] Analog in 54
[7] Pulse input 29
[11] Local bus
reference
P3-10
100%
MG18B302 - Rev. 2013-09-02
Function:
[-100 - Enter up to 8 different preset references (0-7) in
this parameter, using array programming. Select
Preset Reference bit 0/1/2 [16] , [17] or [18] for
the corresponding digital inputs in parameter
group 5-1* Digital Inputs, for selecting dedicated
references. See also Table 3.4
Function:
[ 0 - 400.0 The jog speed is a fixed output speed at
which the frequency converter is running
when the jog function is activated.
See also 3-80 Jog Ramp Time.
Function:
Define fixed value in % to be added to variable
value defined in 3-18 Relative Scaling Reference
Resource, Relative Scaling Reference Source.
The sum of fixed and variable values (labelled Y in
Illustration 3.5) is multiplied with actual reference
(labelled X in Illustration 3.5). This product is added
to actual reference
X + X ×
Y
Relative
X Z=X+X*Y/100
Illustration 3.5 Preset Relative Reference
Function:
Select the input to be used for the first
reference signal. 3-15 Reference 1 Source,
3-16 Reference 2 Source and
3-17 Reference 3 Source define up to
three different reference signals. The
sum of these reference signals defines
the actual reference.
Y
100
Resulting
Z
actual
reference
