5.2.5 12-8* Other Ethernet Services

12-80 FTP Server
Option: Function:
[0] Disabled Disables the built-in FTP server.
[1] Enabled Enables the built-in FTP server.
12-81 HTTP Server
Option: Function:
[0] Disabled
[1] Enabled Enables the built-in HTTP (web) server.
12-82 SMTP Service
Option: Function:
[0] Disabled
[1] Enabled Enables the SMTP (e-mail) service on the option.
12-89 Transent Socket Channel Port
Range: Function:
0 [0–9999] Configures the TCP port-number for the transent
*
socket channel. This enables Frequency converter-
telegrams to be sent transently on Ethernet via
TCP. Default value is 4000, 0 means disabled.

5.2.6 12-9* Advanced Ethernet Settings

12-90 Cable Diagnostic
Option: Function:
Enables/disables advanced Cable diagnosis
function. If enabled, the distance to cable errors
can be read out in 12-93 Cable Error Length. The
parameter resumes to the default setting of Disable
after the diagnostics have finished.
[0] Disabled
[1] Enabled
NOTICE
The cable diagnostics function is only issued on ports
where there is no link (see 12-10 Link Status, Link Status)
12-91 Auto Cross-Over
Option: Function:
[0] Disable Disables the auto cross-over function.
[1] Enable Enables the auto cross-over function.
*
NOTICE
Disabling of the auto cross-over function requires crossed
Ethernet cables for daisy-chaining the options.
MCA 122 Modbus TCP
12-92 IGMP Snooping
Option:
[0]
[1]
12-93 Cable Error Length
Range:
0
*
12-94 Broadcast Storm Protection
Range:
-1 %
-1 %
12-95 Broadcast Storm Filter
Option:
[0] Broadcast only
[1] Broadcast &
®
