8.10.3 Power monitoring

® ®
112 ECOTAP VPD CONTROL PRO
Delay time limit value
You can use this parameter to set the delay time in order to delay the issuing
of the event message.
Behavior limit value
You can use this parameter to set the behavior of the device when the event
message is issued. You can select the following options:
Setting
Off
Auto blocking
Auto/manual blocking
Table 36: Behavior when an event message is issued
For monitoring the transformer's current power, you can set the following
limit values:
Measured value
Apparent power
Active power
Reactive power
Power factor (amount)
Table 37: Limit values for power monitoring
You can set the following parameters for each limit value:
▪ Limit value: Absolute limit value
▪ Hysteresis limit value
▪ Delay time limit value
5252433/02 EN
Behavior
The limit value is not monitored.
▪ An event message is issued.
▪ Automatic regulation is blocked.
▪ An event message is issued.
▪ Automatic regulation is blocked.
▪ You cannot perform tap-change operations in manual
mode.
Lower limit Lower limit
2 1
S<< S<
P<< P<
Q<< Q<
|cos φ|<< |cos φ|<
Maschinenfabrik Reinhausen GmbH 2018
8 Operation
Upper limit Upper limit
1 2
S> S>>
P> P>>
Q> Q>>
- -
