8 Operation

8.18.1 Linking functions

Maschinenfabrik Reinhausen GmbH 2018

8.18 Linking signals and events

The devices allows you to link control system commands (SCADA) with de-
vice functions, and events with control system messages.
The system commands available are each permanently linked to a Generic
SCADA command event message for this purpose.
Command
Generic SCADA command 1
Generic SCADA command 2
...
Generic SCADA command 10
Table 61: Linking of control system commands with event messages
You can link the event messages to device functions and control system
messages. You can also link all other event messages (e.g. Undervoltage
U<) to control system messages. Corresponding parameters, for which you
need to enter the relevant event number, are provided for this purpose.
You can link the Generic SCADA command events to device functions. This
allows you to remotely control the device via the control system (SCADA).
Depending on your device configuration, the following parameters are avail-
able for this purpose:
Parameters
Master parallel operation method
Follower parallel operation method
Automatic tap synchronization parallel
operation method
Independent regulation
Deactivate parallel operation
Blocking
Activate remote mode
High-speed return
5252433/02 EN
Event message
Generic SCADA command 1
Generic SCADA command 2
...
Generic SCADA command 10
Description
If the assigned event is active, the device
activates the master parallel operation
method.
If the assigned event is active, the device
activates the follower parallel operation
method.
If the assigned event is active, the device
activates the automatic tap synchroniza-
tion parallel operation method.
If the assigned event is active, the device
activates simplex mode.
If the assigned event is active, the device
deactivates parallel operation.
If the assigned event is active, automatic
voltage regulation is blocked.
If the assigned event is active, the device
activates remote mode.
If the assigned event is active, the device
activates high-speed return.
® ®
