8 Operation

8.12.4 Setting synchronization interval

8.12.5 Reference time

8.13.1 User roles

Maschinenfabrik Reinhausen GmbH 2018
You can use this parameter to set the interval at which the device is to call
up the time from the time server.
To set the synchronization interval, proceed as follows:
1. Go to Settings > Parameters > Time synchronization > Synchroniza-
tion interval.
2. Enter synchronization interval.
3. Press the Accept button to save the modified parameter.
You can use this parameter to set the reference time for time synchroniza-
tion that the device is to adopt and display. The following options are avail-
able:
Option
UTC
Local time
Table 49: Reference time
To set the reference time, proceed as follows:
1. Go to Settings > Parameters > Time synchronization > Reference
time.
2. Select the option you want.
3. Press the Accept button to save the modified parameter.

8.13 User administration

User administration is based on a system of roles. You must assign a role to
every user. You can define access rights to parameters and events for each
role.
The access rights to device functions and settings are controlled using a hi-
erarchical system of roles. The system has 5 different roles with different ac-
cess rights. Some of these access rights are fixed, but you can configure the
access rights to particular parameters and events. Note the Setting access
rights to parameters and events [►Section 8.13.4, Page 149] section.
If you are not logged in on the device, you will assume the "Data display"
user role.
5252433/02 EN
Description
The set UTC time is applied
The local time of the device is applied
® ®
ECOTAP VPD CONTROL PRO 145
