MR ECOTAP VPD CONTROL PRO Operating Instructions Manual page 182

® ®
182 ECOTAP VPD CONTROL PRO
Description
Interfaces
Redundancy protocols
Time synchronization
RJ45
Fiber-optic cable
Table 77: Technical data for the SW 3-3 assembly
1)
Factory setting
Interfaces
Interface
Table 78: ETHxx (RJ45)
Interface
Table 79: ETHxx (duplex LC SFP)
5252433/02 EN
SW 3-3
Managed Fast Ethernet Switch in accordance with
IEEE 802.3, store-and-forward-switching
2x RJ45
2x duplex LC (SFP)
1
PRP , RSTP
PTPv2 (IEEE 1588-2008)
Max. 100 m (per section)
10/100 Mbit/s
Cable impedance 100 Ω
Max. 2,000 m
100 Mbit/s
Light-emitting diode: class 1
Wave length: 1310 nm
Max. optical output power: <1 mW (in accordance
with IEC 60825-1:2014)
Pin Description
1 TxD+
2 TxD-
3 RxD+
4 NC
5 NC
6 RxD-
7 NC
8 NC-
Description
Fiber glass 50/125 and 62.5/125 multimode
Maschinenfabrik Reinhausen GmbH 2018
12 Technical data
