6 Mounting

6.5.7 Wiring the MC 2-2/SW3-3 assembly

1. Insert the supplied SFP module into the corresponding Ethernet interface
in accordance with the connection diagram and fold the clasp down.
Figure 41: Engaging the SFP module
2. Remove the SFP module dust plug.
Figure 42: Removing the dust plug
® ®
56 ECOTAP VPD CONTROL PRO 5252433/02 EN Maschinenfabrik Reinhausen GmbH 2018
