8 Operation

8.17.1 Exporting data

Maschinenfabrik Reinhausen GmbH 2018
You can export the following data from the device, depending on your device
configuration:
Option Description
System image Complete image of the system (software and configuration). If you
are using the option "with history", all of the event memory entries
are also exported.
System config- System configuration
uration
Customer pro- Customer program export (TPLE).
gram
Event memory All event memory entries.
Recorder Measured value memory export.
Parameter list Parameter list with descriptive texts and values (min, max, current).
Event list Complete list of all possible events.
SCADA config- Control system configuration (e.g. ICD file for IEC 61850).
uration
Operating In- Operating instructions, protocol specifications.
structions
Settings Configuration of parameters and events.
Data point con- Data point configuration of the control system.
figuration
Sensor bus de- Sensor description of the sensors for MR sensor bus that have
vice desc. been created with the sensor editor.
Security log Logbook of all instances of access and amendments relating to se-
curity.
Table 59: Exporting data
Only remove the USB stick once the data transfer is complete. Otherwise
data may be lost.
To export data, proceed as follows:
1. Go to Settings > Export.
2. Select the desired option for the export.
5252433/02 EN
® ®
ECOTAP VPD CONTROL PRO 169
