8.2.4.1 Configuring visualization
® ®
68 ECOTAP VPD CONTROL PRO
To set the measurement transformer display, proceed as follows:
1. Go to Settings > Parameters > General > Measured value display.
2. Select the option you want.
3. Press the Accept button to save the modified parameter.

8.2.3 Remote behavior

You can use this parameter to select the behavior of the device in remote
operating mode. You can select the following options:
Option
Hardware only
SCADA only
Hardware and SCADA
Table 12: Selecting Remote behavior
To set the Remote behavior, proceed as follows:
1. Go to Settings > Parameters > General > Remote behavior.
2. Select the desired option.
3. Press the Accept button to save the modified parameter.

8.2.4 Visualization

The device is equipped with a web-based visualization. This allows you to
configure the device with a computer and to display measured values.
You can establish a link to the visualization via the ETH2.2 interface on the
CPU assembly (for access via remote display, control center etc.).
System requirements
To access the web-based visualization, you need a PC with an HTML5-ca-
pable browser. The display is optimized for the following browsers:
▪ Microsoft® Internet Explorer 10 or higher
▪ Google Chrome™
To establish a connection to the visualization, please observe the following
sections.
You can use the following parameters to configure the interface for the visu-
alization. The following parameters are available:
▪ IP address
▪ Subnet mask
Description
No function.
The device accepts commands via SCADA.
The device accepts commands via SCADA.
5252433/02 EN
8 Operation
Maschinenfabrik Reinhausen GmbH 2018
