8 Operation
Maschinenfabrik Reinhausen GmbH 2018
Signal Description
Q L1 Reactive power L1
Q L2 Reactive power L2
Q L3 Reactive power L3
Q Total reactive power
Tx1: t motor Motor runtime transformer 1
Tx2: t motor Motor runtime transformer 2
Tx3: t motor Motor runtime transformer 3
Tx4: t motor Motor runtime transformer 4
Tx1: Q1 Off Motor protective switch triggered transformer 1
Tx2: Q1 Off Motor protective switch triggered transformer 2
Tx3: Q1 Off Motor protective switch triggered transformer 3
Tx4: Q1 Off Motor protective switch triggered transformer 4
Par. grp. 1 Parallel operation group 1 active
Par. grp. 2 Parallel operation group 2 active
Table 55: Measured values and signals
Signal Description
P_m L1 Active power L1 (average value)
W1: P_m L1 Winding 1: Active power L1 (average value)
W1: P_m L2 Winding 1: Active power L2 (average value)
W1: P_m L3 Winding 1: Active power L2 (average value)
W1: P_m Winding 1: Active power in total (average value)
W1: S_m L1 Winding 1: Apparent power L1 (average value)
W1: S_m L2 Winding 1: Apparent power L2 (average value)
W1: S_m L3 Winding 1: Apparent power L3 (average value)
W1: S_m Winding 1: Apparent power in total (average value)
W1: U_m Desired Winding 1: Desired voltage value (average value)
W1: f_m Winding 1: Frequency (average value)
W1: φ_m U1/I1 Winding 1: Phase angle U1/I1 (average value)
W1: φ_m U2/I2 Winding 1: Phase angle U2/I2 (average value)
W1: φ_m U3/I3 Winding 1: Phase angle U3/I3 (average value)
W1: cos(φ_m) L1 Winding 1: Power factor L1 (average value)
W1: cos(φ_m) L2 Winding 1: Power factor L2 (average value)
W1: cos(φ_m) L3 Winding 1: Power factor L3 (average value)
W1: cos(φ_m) Winding 1: Power factor in total (average value)
W1: I_m N Winding 1: Neutral conductor current (average value)
