Product Introduction

Your Application
The Danfoss AK-System Manager (AK-SM) is a modern solution for
the food retail markets. The AK-SM uses the latest technology to
provide the maximum benefit to the end user, both in terms of
energy saving optimization, control options and user friendly
access. Designed specifically with the food retail applications in
mind, the AK-SM provides all the functionality and tools to
provide full application 'coverage', for the Refrigeration control
and monitoring application.
The Danfoss AK-SM represents the most flexible answer to today's
demands & balances cost effective control, continuous energy
optimization and long term flexibility via miscellaneous inputs
and boolean logic commands, all built in to one easy to use front
end controller.
Modern Technology at work for you
Modern tools like the built-in USB flash drive port allows for easy
firmware updating & saving of the database. All part of the AK-SM
package is the Remote Management Tool, a simple yet powerful
application that allows remote updates, software management
and the saving of databases on the AK-SM. Full remote access is
powered by the AK-SM built in web server, providing you with an
advanced web browser environment in which to control, view &
monitor all your important assets.
AK-SM Headline Features
*License dependent
Refrigeration Control (centralized and de-centralized methods)
Energy saving technology (built in)
Schedules Groups
Flexible Alarm Routing / Output
Built in Modbus, LonWorks® network
Full color VGA Local screen view & access
Built in Buzzer & 2-tone LED
Support for Danfoss AK I/O modules
Local screen custom graphics
Consolidated store view
600 History points
Web browser custom graphics
Multiple users / user levels
Multiple language support
USB flash drive support (load,save and update software)
Full web browser access
Built in Boolean Logic commands
Remote Management Tool
Service Tool support
4
Control and monitor your Refrigeration application via centralized (Rack) or
de-centralized (Case/Pack) dependent on your control needs.
Master control, Suction optimization, scheduling, enterprise load shed
Central Defrost, Case lighting, Store / Outside Lighting, Night setback, Shutdown
e-mail, IP address, relay
More scope for control solutions - Established protocols
Access all areas of your system from easy to use local screen
Easy local level alarm notification
I/O module support offering extended and flexible control, monitoring
Create simple & clear graphic screen with only 'key parameters' shown - simply
the management of your services
Show a consolidated web view of your store, not just individual AK-SM controllers.
View all data from all interconnected AK-SM devices in common web browser
pages
Large history storage capacity to ensure HACCP compliance & service level detail
Create custom web graphics that present in the AK-SM web screens. Map any
datapoint from any AK-SM controller and vizualize in the web
Definable user list with clear authorization levels
Local & Browser language support
Reduce commissioning time & Cost
Standard web browser connection provides access to all areas of the system
Create your own logic to control even the most obscure application
Remotely manage your system - Update software, save database, controller file
management, load images, allowing custom image & mapping of parameters
Gain access to Danfoss AK2 based controls via Service Tool tunneling
User Guide USCO.PI.R1.E1.02 © Danfoss 07-2013
Lit. no.
Benefits
AK-SM 850
