Mirror Port Commands

This section describes how to mirror traffic from a source port to a target
port.
Command

port monitor

show port
monitor
port monitor
This command configures a mirror session. Use the no form to clear a
mirror session.
Syntax
port monitor interface [rx | tx]
no port monitor interface
• interface - ethernet unit/port (source port)
• rx - Mirror received packets.
• tx - Mirror transmitted packets.
Default Setting
No mirror session is defined.
Command Mode
Interface Configuration (Ethernet, destination port)
Command Usage
• You can mirror traffic from any source port to a destination port for
real-time analysis. You can then attach a logic analyzer or RMON
probe to the destination port and study the traffic crossing the source
port in a completely unobtrusive manner.
4-156
I
NTERFACE
Table 4-42 Mirror Port Commands
Function
Configures a mirror session
Shows the configuration for a mirror port
- unit - Stack unit.
(Range – SMC6224M: 1-8, SMC6248M: 1-4, mixed stack: 1-4)
- port - Port number. (Range: 1-26/50)
Mode Page
IC 4-156
PE 4-157
