Figure 3-16 Remote Logs - SMC Networks SMC TigerStack IV SMC6224M Management Manual

Web – Click System, Log, Remote Logs. To add an IP address to the Host
IP List, type the new IP address in the Host IP Address box, and then click
Add. To delete an IP address, click the entry in the Host IP List, and then
click Remove.
CLI – Enter the syslog server host IP address, choose the facility type and
set the logging trap.
Console(config)#logging host 192.168.1.15
Console(config)#logging facility 23
Console(config)#logging trap 4
Console(config)#end
Console#show logging trap
Syslog logging:
REMOTELOG status:
REMOTELOG facility type:
REMOTELOG level type:
REMOTELOG server ip address: 192.168.1.15
REMOTELOG server ip address: 0.0.0.0
REMOTELOG server ip address: 0.0.0.0
REMOTELOG server ip address: 0.0.0.0
REMOTELOG server ip address: 0.0.0.0
Console#

Figure 3-16 Remote Logs

Enabled
Enabled
local use 7
Warning conditions
B C
ASIC ONFIGURATION
4-60
4-61
4-62
4-62
3-37
