Displaying LACP Port Counters

You can display statistics for LACP protocol messages.
Field
LACPDUs Sent
LACPDUs Received
Marker Sent
Marker Received
LACPDUs Unknown
Pkts
LACPDUs Illegal Pkts
Web – Click Port, LACP, Port Counters Information. Select a member
port to display the corresponding information.

Figure 3-45 LACP - Port Counters Information

Table 3-6 LACP Port Counters

Description
Number of valid LACPDUs transmitted from this
channel group.
Number of valid LACPDUs received on this channel
group.
Number of valid Marker PDUs transmitted from this
channel group.
Number of valid Marker PDUs received by this channel
group.
Number of frames received that either (1) Carry the
Slow Protocols Ethernet Type value, but contain an
unknown PDU, or (2) are addressed to the Slow
Protocols group MAC Address, but do not carry the
Slow Protocols Ethernet Type.
Number of frames that carry the Slow Protocols
Ethernet Type value, but contain a badly formed PDU
or an illegal value of Protocol Subtype.
