Figure 3-72 Port Priority Configuration - SMC Networks SMC TigerStack IV SMC6224M Management Manual

C
ONFIGURING THE
Command Attributes
• Default Priority
received on the specified interface. (Range: 0-7, Default: 0)
• Number of Egress Traffic Classes – The number of queue buffers
provided for each port.
Web – Click Priority, Default Port Priority or Default Trunk Priority.
Modify the default priority for any interface, then click Apply.
CLI – This example assigns a default priority of 5 to port 3.
Console(config)#interface ethernet 1/3
Console(config-if)#switchport priority default 5
Console(config-if)#end
Console#show interfaces switchport ethernet 1/3
Information of Eth 1/3
Broadcast threshold:
LACP status:
Ingress rate limit: disable, Level: 30
Egress rate limit: disable, Level: 30
VLAN membership mode:
Ingress rule:
Acceptable frame type:
Native VLAN:
Priority for untagged traffic: 5
GVRP status:
Allowed VLAN:
Forbidden VLAN:
Private-VLAN mode:
Private-VLAN host-association: NONE
Private-VLAN mapping:
Console#
11. CLI displays this information as "Priority for untagged traffic."
3-170
S
WITCH
11
– The priority that is assigned to untagged frames

Figure 3-72 Port Priority Configuration

Disabled
Disabled
Hybrid
Enabled
Tagged frames only
1
Disabled
1(u),
NONE
NONE
4-143
4-222
4-154
