C
ONFIGURING THE
Web – Click IGMP Snooping, Static Multicast Router Port Configuration.
Specify the interfaces attached to a multicast router, indicate the VLAN
which will forward all the corresponding multicast traffic, and then click
Add. After you have finished adding interfaces to the list, click Apply.

Figure 3-84 Static Multicast Router Port Configuration

CLI – This example configures port 11 as a multicast router port within
VLAN 1.
Console(config)#ip igmp snooping vlan 1 mrouter ethernet 1/11 4-245
Console(config)#exit
Console#show ip igmp snooping mrouter vlan 1
VLAN M'cast Router Port Type
---- ------------------ -------
1
Console#

Displaying Port Members of Multicast Services

You can display the port members associated with a specified VLAN and
multicast service.
Command Attributes
• VLAN ID – Selects the VLAN for which to display port members.
• Multicast IP Address – The IP address for a specific multicast
service.
• Multicast Group Port List – Shows the interfaces that have already
been assigned to the selected VLAN to propagate a specific multicast
service.
3-190
S
WITCH
Eth 1/11 Static
4-246
