Table 4-46 show lacp internal - display description (Continued)
Field Description
Admin State, Administrative or operational values of the actor's state
Oper State parameters:
• Expired – The actor's receive machine is in the expired state;
• Defaulted – The actor's receive machine is using defaulted
• Distributing – If false, distribution of outgoing frames on this
• Collecting – Collection of incoming frames on this link is
• Synchronization – The System considers this link to be
• Aggregation – The system considers this link to be
• Long timeout – Periodic transmission of LACPDUs uses a slow
• LACP-Activity – Activity control value with regard to this link.
operational partner information, administratively configured
for the partner.
link is disabled; i.e., distribution is currently disabled and is not
expected to be enabled in the absence of administrative
changes or changes in received protocol information.
enabled; i.e., collection is currently enabled and is not expected
to be disabled in the absence of administrative changes or
changes in received protocol information.
IN_SYNC; i.e., it has been allocated to the correct Link
Aggregation Group, the group has been associated with a
compatible Aggregator, and the identity of the Link
Aggregation Group is consistent with the System ID and
operational Key information transmitted.
aggregatable; i.e., a potential candidate for aggregation.
transmission rate.
(0: Passive; 1: Active)
L A
INK GGREGATION
C
OMMANDS
4-173
