C
ONFIGURING THE
CLI – This example shows the STA attributes for port 5.
Console#show spanning-tree ethernet 1/5
Eth 1/ 5 information
--------------------------------------------------------------
Admin status
Role
State
Path cost
Priority
Designated cost
Designated port
Designated root
Designated bridge
Fast forwarding
Forward transitions
Admin edge port
Oper edge port
Admin Link type
Oper Link type
Spanning Tree Status : enabled
Console#

Configuring Interface Settings

You can configure RSTP attributes for specific interfaces, including port
priority, path cost, link type, and edge port. You may use a different
priority or path cost for ports of the same media type to indicate the
preferred path, link type to indicate a point-to-point connection or
shared-media connection, and edge port to indicate if the attached device
can support fast forwarding. (References to "ports" in this section means
"interfaces," which includes both ports and trunks.)
Command Attributes
The following attributes are read-only and cannot be changed:
• STA State – Displays current state of this port within the Spanning
Tree. (See Displaying Interface Settings on page 3-136 for additional
information.)
- Discarding - Port receives STA configuration messages, but does
not forward packets.
- Learning - Port has transmitted configuration messages for an
interval set by the Forward Delay parameter without receiving
3-140
S
WITCH
: enabled
: designate
: discarding
: 10000
: 128
: 0
: 128.5
: 61440.0.0000E9313131
: 61440.0.0000E9313131
: disabled
: 0
: disabled
: disabled
: auto
: point-to-point
4-193
