CLI – This example shows the default global setting for 802.1X.
Console#show dot1x
Global 802.1X Parameters
system-auth-control: enable
802.1X Port Summary
Port Name Status
1/1 disabled
1/2 disabled
. .
.
802.1X Port Details
802.1X is disabled on port 1/1
802.1X is disabled on port 26
. .
.
Console#

Configuring 802.1X Global Settings

The 802.1X protocol includes port authentication. The 802.1X protocol
must be enabled globally for the switch system before port settings are
active.
Command Attributes
• 802.1X System Authentication Control – Sets the global setting for
802.1X. (Default: Disabled)
Web – Select Security, 802.1X, Configuration. Enable 802.1X globally for
the switch, and click Apply.
Operation Mode
Single-Host
Single-Host

Figure 3-31 802.1X Configuration

U A
SER UTHENTICATION
Mode
ForceAuthorized
ForceAuthorized
4-112
Authorized
n/a
n/a
3-69
