Displaying Log Messages

The Logs page allows you to scroll through the logged system and event
messages. The switch can store up to 2048 log entries in temporary
random access memory (RAM; i.e., memory flushed on power reset) and
up to 4096 entries in permanent flash memory.
Web – Click System, Log, Logs.
CLI – This example shows the event message stored in RAM.
Console#show log ram
[1] 00:01:37 2001-01-01
"DHCP request failed - will retry later."
level: 4, module: 9, function: 0, and event no.: 10
[0] 00:00:35 2001-01-01
"System coldStart notification."
level: 6, module: 6, function: 1, and event no.: 1
Console#
3-38
S
WITCH

Figure 3-17 Displaying Logs
